MAVO Edge 6K Black
MAVO Edge 6K Black
Previous keyboard_arrow_left
Next keyboard_arrow_right
MAVO Edge 6K Black
MAVO Edge 6K Black

MAVO Edge 6K Black

Kinefinity

Digital Cinema Camera 6K 3:2 Full-Frame CMOS Sensor - Black
go to the technical sheet
₦ 23,378,466.00

₦ 21,747,410.00 VAT excl.

Available in 19 days
Not sure if this is the right product for you? Talk to a consultant
Kinefinity Digital Cinema Camera 6K 3:2 Full-Frame CMOS Sensor, Sensor Resolution 23.97 Megapixel (6016 x 3984) - Black

Capture amazing detail in a variety of resolutions and frame rates to suit all your project needs with the full-frame Black MAVO Edge 6K Cinema Camera from Kinefinity.
This kin to the MAVO Edge 8K camera offers multiple resolutions, formats, and frame rates ranging from S16 2K up to cinematic full-frame 6K, 3:2 open gate.
Widely used codec options for internal recording range from ProRes Proxy up to ProRes 4444 XQ for 6K workflows.
Dual native ISOs of 800 and 5120 enable you to shape its 14 stops of dynamic range around either the highlights or lowlights, and its proprietary color science supports KineLOG3, Rec 709, and custom 3D LUTs.

Choose oversampled 3K or 4K settings to preserve the framing and depth of field of a given lens, or digitally crop to boost its magnification.
A broad selection of glass is at your disposal thanks to the separately available PL, LPL, active EF, and passive E lens adapters for the MAVO Edge 6K's native KineMOUNT lens mount.
This aluminum-body camera's power options include compatibility with V-mount, Sony BP-U, and Sony L-Series batteries.

° Sharp, Multiformat 6K Sensor
Use the full 6016 x 3984, 23.97MP sensor for outstanding detail in full-frame 6K 3:2 open gate at rates up to 48 fps, crop to 6K 17:9 to overcrank up to 60 fps, or choose between multiple S16, S35, and full-frame aspect ratios and frame rates.
For breathtaking slow motion, S16 2K up to 290 fps offers mesmerizing action, sport, or wildlife imaging.

° Impressive Image Quality
The MAVO 6K Edge's in-camera recording of ProRes 4444 XQ enables maximum flexibility in color grading.
KineLOG3, its proprietary color science, is primed for applying a custom 3D LUT for attaining a specific aesthetic.

° Universal KineMOUNT
The proprietary KineMOUNT is designed to be used with separately available PL, LPL, active EF, and passive E mount adapters.
This versatility enables you to take advantage of a wide selection of both cine-style and still photo lenses in PL, LPL, active EF, and passive E mounts.

° Dual Native ISO
Dual Native ISOs of 800 and 5120 span the range of daylight exteriors to night exteriors, enabling you to shape your exposure to match an ambient light source using a smaller number of lighting fixtures or none at all.

° Electronic ND Filter
The motorized e-ND enables precise control over the exposure without affecting the depth of field or motion smoothness in your footage.
Continuous tuning of the density from 0.6 to 2.4 translates to the ability to make detailed reductions in exposure between 2 and 8 stops.

° Power Options
The camera body is compatible with numerous power options, including KineBAT, V-mount, and Sony L-Series batteries.

° Dual Media Slots
Dual SSD slots for recording to fast NVMe M.2-based KineMAG Nano SSD cards.

° XLR Audio Inputs
Capture professional sound using the MAVO Edge 6K's dual XRL audio inputs.

° Monitoring
Dual 1.5G-/3G-SDI outputs for monitoring with embedded metadata and audio plus dual proprietary Kinefinity Video ports for KineMon and OLED EVF use.

° Connectivity
Connectivity features include timecode input and output, RS-232 and Kinefinity syncing, and a 3-pin Fischer run/stop port.
Touchscreen control is available using the Kinefinity app or the separately available Kinefinity app.

S-2620
Swit

S-2620

₦ 420,485.00 VAT included
Available 1 unit in 4 Days
PL-E90
Swit

PL-E90

₦ 742,878.00 VAT included
Available 3 unit in 4 Days
PL-E60D
Swit

PL-E60D

₦ 833,661.00 VAT included
Available 2 unit in 4 Days
PL-E90D
Swit

PL-E90D

₦ 1,196,205.00 VAT included
Available 1 unit in 4 Days
S-2610
Swit

S-2610

₦ 539,165.00 VAT included
Available in 11 days
LS 300X
Aputure

LS 300X

₦ 2,350,486.00 VAT included
Available in 15 days
ARRI T1 1000
Arri

ARRI T1 1000

₦ 1,562,028.00 VAT included
Available in 8 days
ARRI T2 2000
Arri

ARRI T2 2000

₦ 1,792,508.00 VAT included
Available in 8 days
FF-T07
Tilta

FF-T07

₦ 132,224.00 VAT included
Available 1 unit in 4 Days
FF-T05
Tilta

FF-T05

₦ 1,972,194.00 VAT included
Available in 14 days
FF-T03
Tilta

FF-T03

₦ 1,026,033.00 VAT included
Available in 14 days
S-8110S
Swit

S-8110S

₦ 393,019.00 VAT included
Available 2 unit in 4 Days
S-8180S
Swit

S-8180S

₦ 684,989.00 VAT included
Available 2 unit in 4 Days
VL-B100USB
ON-AIR

VL-B100USB

₦ 294,065.00 VAT included
Available 6 unit in 4 Days
306-0212
MovCam

306-0212

₦ 635,969.00 VAT included
Available 1 unit in 4 Days
S-8082S
Swit

S-8082S

₦ 289,819.00 VAT included
Available 2 unit in 4 Days
S-8192S
Swit

S-8192S

₦ 700,523.00 VAT included
Available 1 unit in 4 Days
PB-S98S
Swit

PB-S98S

₦ 222.00 VAT included
Available 8 unit in 4 Days
S-8083S
Swit

S-8083S

₦ 405,919.00 VAT included
Available 2 unit in 4 Days
S-8113S
Swit

S-8113S

₦ 502,346.00 VAT included
Available 2 unit in 4 Days
H3-VR
Zoom

H3-VR

₦ 455,799.00 VAT included
Available 5 unit in 4 Days
H5
Zoom

H5

₦ 393,019.00 VAT included
Available in 14 days
DR-40X
Tascam

DR-40X

₦ 393,180.00 VAT included
Available 3 unit in 4 Days
DR-10X
Tascam

DR-10X

₦ 303,794.00 VAT included
Available in 11 days
MixPre-10 II
Sound Devices

MixPre-10 II

₦ 3,944,013.00 VAT included
Available 2 unit in 4 Days
H2n
Zoom

H2n

₦ 213,225.00 VAT included
Available 1 unit in 4 Days
F6
Zoom

F6

₦ 1,066,560.00 VAT included
Available 2 unit in 4 Days
MixPre-3 II
Sound Devices

MixPre-3 II

₦ 2,033,845.00 VAT included
Available 2 unit in 4 Days
MixPre-6 II
Sound Devices

MixPre-6 II

₦ 2,395,099.00 VAT included
Available 1 unit in 4 Days
R8
Zoom

R8

₦ 530,350.00 VAT included
Available in 19 days
DR-10CS
Tascam

DR-10CS

₦ 476,331.00 VAT included
Available in 11 days
DR-70D
Tascam

DR-70D

₦ 683,699.00 VAT included
Available in 11 days
DR-60DMK2
Tascam

DR-60DMK2

₦ 471,010.00 VAT included
Available 2 unit in 4 Days
DR-05X
Tascam

DR-05X

₦ 175,331.00 VAT included
Available 1 unit in 4 Days
NTG-2
Rode

NTG-2

₦ 487,458.00 VAT included
Available 3 unit in 4 Days
ECM-55B
Sony

ECM-55B

₦ 1,139,553.00 VAT included
Available in 14 days
ECM-MS2
Sony

ECM-MS2

₦ 596,731.00 VAT included
Available 2 unit in 4 Days
ECM-77B
Sony

ECM-77B

₦ 1,155,301.00 VAT included
Available in 14 days
ECM-678
Sony

ECM-678

₦ 2,009,980.00 VAT included
Available in 14 days
NTG-3 Black
Rode

NTG-3 Black

₦ 1,390,135.00 VAT included
Available in 14 days
ECM-44B
Sony

ECM-44B

₦ 625,165.00 VAT included
Available 2 unit in 4 Days
NTG-8
Rode

NTG-8

₦ 2,093,615.00 VAT included
Available 1 unit in 4 Days
NTG-4
Rode

NTG-4

₦ 557,763.00 VAT included
Available 1 unit in 4 Days
ECM-77LM
Sony

ECM-77LM

₦ 700,361.00 VAT included
Available in 14 days
NTG-1
Rode

NTG-1

₦ 466,925.00 VAT included
Available 1 unit in 4 Days
ECM-VG1
Sony

ECM-VG1

₦ 422,044.00 VAT included
Available in 14 days
NTG-3
Rode

NTG-3

₦ 1,390,135.00 VAT included
Available 3 unit in 4 Days
ECM-680S
Sony

ECM-680S

₦ 2,351,776.00 VAT included
Available in 14 days
NTG-5
Rode

NTG-5

₦ 1,197,656.00 VAT included
Available in 14 days
ECM-674
Sony

ECM-674

₦ 1,088,221.00 VAT included
Available 1 unit in 4 Days
ECM-673
Sony

ECM-673

₦ 868,599.00 VAT included
Available in 14 days
NTG-4 PLUS
Rode

NTG-4 PLUS

₦ 597,645.00 VAT included
Available in 14 days
Mars T1000
Hollyland

Mars T1000

₦ 2,935,286.00 VAT included
Available in 29 days
Boompole
Rode

Boompole

₦ 274,876.00 VAT included
Available 3 unit in 4 Days
Boompole Micro
Rode

Boompole Micro

₦ 135,771.00 VAT included
Available 3 unit in 4 Days
Boompole PRO
Rode

Boompole PRO

₦ 515,139.00 VAT included
Available 2 unit in 4 Days
Boompole Mini
Rode

Boompole Mini

₦ 231,446.00 VAT included
Available 2 unit in 4 Days
S-2070
Swit

S-2070

₦ 152,703.00 VAT included
Available 3 unit in 4 Days
BVM-HX310
Sony

BVM-HX310

₦ 49,803,298.00 VAT included
Available in 14 days
DT-E21L4
JVC

DT-E21L4

₦ 4,140,738.00 VAT included
Available in 14 days
BVM-E251
Sony

BVM-E251

₦ 19,085,925.00 VAT included
Available in 64 days
FLOW500
Swit

FLOW500

₦ 1,429,856.00 VAT included
Available in 11 days
COSMO C1
Hollyland

COSMO C1

₦ 987,978.00 VAT included
Available 3 unit in 4 Days
KF-APT-1
Kinefinity

KF-APT-1

₦ 1,106,873.00 VAT included
Available in 14 days
CIAK STD
ON-AIR

CIAK STD

₦ 89,976.00 VAT included
Available 15 unit in 4 Days

Imaging
Lens Mount: KineMOUNT
Lens Communication: Yes
Sensor Resolution: Effective: 23.97 Megapixel (6016 x 3984)
Image Sensor: Full-Frame CMOS
Image Stabilization: No
Built-In ND Filter: 0.6 to 2.4 Stop Electronic ND Filter
Internal Filter Holder: Yes
Capture Type: Video Only

Exposure Control
Shutter Type: Electronic Rolling Shutter
Shutter Type: Electronic Rolling Shutter
Shutter Speed: 0.7 to 358 Second
ISO Sensitivity Range: 800 to 5120
Shutter Angle: 0.7 to 358°
Advertised Dynamic Range: 14 Stops

Video Capture
- Internal Recording Modes:
MOV/ProRes 422 HQ/ProRes 422 Proxy/ProRes 422LT/ProRes 4444/ProRes 4444XQ
6016 x 3984 from 0.2 to 48.00 fps
6016 x 3172 from 0.2 to 60.00 fps
6016 x 2520 from 0.2 to 75 fps
5760 x 3700 from 0.2 to 50 fps
5760 x 3240 from 0.2 to 58 fps
5760 x 2400 from 0.2 to 75 fps
5120 x 3700 from 0.2 to 50 fps
5120 x 2700 from 0.2 to 70 fps
5120 x 2160 from 0.2 to 86 fps
4608 x 3700 from 0.2 to 50 fps
4096 x 2700 from 0.2 to 70 fps
4096 x 2160 from 0.2 to 112 fps
4096 x 1720 from 0.2 to 140 fps
3840 x 2460 from 0.2 to 50 fps
3840 x 2160
3840 x 1600 from 0.2 to 150 fps
3712 x 2700 from 0.2 to 70 fps
3456 x 2460 from 0.2 to 50 fps
3328 x 2700 from 0.2 to 70 fps
3072 x 2460 from 0.2 to 50 fps
3072 x 1620 from 0.2 to 144 fps
3072 x 1200 from 0.2 to 195 fps
2944 x 1620 from 0.2 to 145 fps
2944 x 1200 from 0.2 to 195 fps
2688 x 2688 from 0.2 to 70 fps
2048 x 1080 from 0.2 to 200 fps
2048 x 860 from 0.2 to 270 fps
1920 x 1080 from 0.2 to 220 fps
1920 x 800 from 0.2 to 290 fps
° Sensor Crop Modes
Super35 / APS-C
4K (4096 x 3432)
4K (4096 x 3072)
4K (4096 x 2160)
4K (4096 x 1720)
4K (3840 x 2160)
4K (3840 x 1600)
3K (3072 x 3072)
2K (2048 x 1080)
2K (2048 x 860)
2K (1920 x 1080)
2K (1920 x 1080)
° Four Thirds
3K (3072 x 1620)
3K (3072 x 1200)
3K (2944 x 1620)
3K (2944 x 1200)
° Super16
2K (2048 x 1080)
2K (2048 x 860)
2K (1920 x 1080)
2K (1920 x 800)
° Sensor Crop While Recording
6K (6016 x 3172) in 17:9
6K (6016 x 2520)
6K (5760 x 3240)
6K (5760 x 2400)
5K (5376 x 3984) in 4:3
5K (5120 x 2704)
5K (4864 x 3984)
5K (4864 x 3984) in 6:5
4K (3840 x 2672)
4K (3840 x 2160)
4K (3840 x 1600)
3K (2944 x 1620)
3K (2944 x 1200)
Fast-/Slow-Motion Support: Yes
Gamma Curve: KineLOG3, Rec709
Built-In Microphone Type: Mono
Audio Recording: 1-Channel
IP Streaming: No

Interface
Media/Memory Card Slot: Dual Slot: KineMAG Nano SSD
Video I/O:
- 2 x BNC (3G-SDI) Output
- 2 x Proprietary (3G-SDI) Output
Audio I/O:
- 2 x XLR 3-Pin (+48 V Phantom Power) Input
- 1 x 1/8" / 3.5 mm TRRS Headphone/Mic Microphone Input
- 1 x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Output
Power I/O: 1 x LEMO 2-Pin Input
Other I/O:
- 1 x USB-C
- 1 x RJ45 (Gigabit Ethernet) Control
- 1 x LEMO 5-Pin (Timecode) Control Input/Output
- 1 x LEMO 6-Pin Control
- 1 x LEMO 7-Pin (RS-232) Control
- 1 x Fischer 3-Pin Control
- 2 x Pogo 10-Pin Control Input/Output
Wireless: Wi-Fi
Mobile App Compatible:
No
*As of May, 2023: Check with manufacturer for the most up-to-date compatibility
Global Positioning (GPS, GLONASS, etc.): No

Environmental
Operating Temperature: 32 to 104°F / 0 to 40°C

General
Power Consumption: 32 W
Tripod Mounting Thread:
- 1/4"-20 Female
- 3/8"-16 Female
Material of Construction: Aluminum
Dimensions (W x H x D): 4.9 x 4.3 x 4.2" / 124 x 109 x 106 mm
Weight: 3.6 lb / 1.6 kg (Body Only)

Kinefinity MAVO Edge 6K Digital Cinema Camera (Black)

Other products in the same category

Previous
Next
PYXIS 6K EF
Blackmagic

PYXIS 6K EF

₦ 6,143,033.00 VAT included
Available 1 unit in 4 Days
Z-CAM E2-S6G EF
Z Cam

Z-CAM E2-S6G EF

₦ 10,769,725.00 VAT included
Available 2 unit in 4 Days
ILME-FX30.CEC
Sony

ILME-FX30.CEC

₦ 4,046,675.00 VAT included
Available 3 unit in 4 Days
MAVO mark2 LF
Kinefinity

MAVO mark2 LF

₦ 14,026,119.00 VAT included
Available in 19 days
