PD570 PRO SDI

Name: PD570 PRO SDI
Brand: Yuan
SKU: PD570 PRO SDI
Price: 371143 NGN
Availability: OutOfStock

Yuan

USB 3.0 Video capture box with SDI and analog audio inputs

go to the technical sheet

₦ 371,143.00

₦ 345,249.00 VAT excl.

Available in 14 days

Manufacturer: go to website

Not sure if this is the right product for you? Talk to a consultant

Product description
Specifications

USB 3.0 Video capture box with SDI and analog audio inputs
The card is UVC compliant so it's detected by the computer's OS as a webcam, allowing the direct use with software like Skype or Web-Ex(for video calls) or streaming platforms like Youtube and Facebook.
It supports resolutions up to 1080p60(for Level B SDI sources it doesn't not support 1080i)

OS Support Windows 7 / Windows 8 / Windows 8.1
Windows 10 ( 32-bit and 64-bit )
Linux / MAC OS / Android
USB 3,0 cable included

For audio/video settings you can download the utility from this link(Windows Only at the moment)

Max. Input Resolution 1920×1200p@60/50fps
Recording Mode Software Compression, Real-Time Mode
Interface USB3.0 ( SuperSpeed ) UVC
Video Input 1×SDI
Video RAW Data Format YUY2
Video Input Resolution All Resolution Below 1920×1200p@60fps
Recording Video Format YUY2 ( USB3.0 )
UVC Video Output Resolution 1920×1200p@60/50/30/25/24fps
1920×1080p@60/50/30/25/24fps
1280×1024p@60/50/30/25/24fps
1280×720p@60/50/30/25/24fps
1024×768p@60/50/30/25/24fps
800×600p@60/50/30/25/24fps
640×480p@60/50/30/25/24fps
Audio Input SDI Embedded Audio
3.5mm Analog Stereo Audio
UAC Audio Output Format Stereo / 16-bit / 48000Hz
System Requirement
OS Support Windows 7 / Windows 8 / Windows 8.1
Windows 10 ( 32-bit and 64-bit )
Linux / MAC OS / Android
