With it you can stream live video for interviews, corporate conferences / webinars, school lectures, church worship services, or live events, all in full HD quality.
CAMLIVE™ PRO is designed to make it easy to capture and mix two connected 4K video sources into FHD format for live streaming with stunning video effects and stunning image quality. It supports switching between multiple connected sources as well as combining them to provide richer information during streaming. It also automatically converts the sources into the crisp looking USB video format in 720P or 1080P sent to your laptop/smartphone via USB. CAMLIVE™ PRO offers an intuitive ATEN OnAir Lite application. The application puts everything you need to customize your live streaming at your fingertips. You can be anywhere by simply changing the background for exciting effects. CAMLIVE™ PRO, the dedicated application and your laptop/smartphone, is all you need to present stunning live streams and compete with the most advanced streamers on social media as well as offering an easy-to-use solution.
Mix and capture two live non-HDCP 4K videos in UVC 1080P format to PC or mobile devices via USB 3.x interface with stunning transitions
° Intuitive Android/iOS App Control
&emsp,- Set up the camera and control your recording from anywhere
&emsp,- Multi-Crop function with 4K resolution input capability, users can crop multiple images from connected HDMI sources, resize them and fit them into different scenarios
&emsp,- Remote Deck function customizes up to 18 hotkeys for full control of OBS or other streaming software installed on the host device
° Supports real-time HDMI program video preview
° Easily identifiable chroma keys - allows users to appear anywhere they want by changing the background
° Offers an audio mixer with additional dual analog audio inputs
° Supports protected video switching mode for use in normal events
° Compatible with USB and Thunderbolt 3 (USB-C) specifications
Connectors
Video Input: 2 x HDMI Type-A Female (Black)
USB Port: USB 3.2 Gen1 Type-B Male (Blue) (USB-B to USB-C and USB-B to USB-A Cable Pack Included)
Video Output: 1 x HDMI Type-A Female (Video PGM, Black)
Audio Inputs:
- 1 x Balanced Analog Audio via XLR Connectors
- 1 x Unbalanced Audio via RCA Connectors
Video Resolution
- Video Inputs: Supports 2160p30/25/24, 1080p60/50/30/25/24, 720p60/50, HDMI
- PGM Video Output: Supports 1080p60/50/30/25/24, 720p60/50, HDMI (unencrypted)
(Encrypted PGM output supported at 2160p30/25/24, 1080p60/50/30/25/24, 720p60/50 with UVC capture disabled)
Audio Sampling
16-bit PCM audio, 44.1KHz and 48KHz
Output
UVC video streaming 1080p60 and 720p60 uncompressed with UAC audio
(Uncompressed video streaming is only available with USB 3.1 connection)
Environment
Operating temperature: 0 - 40°C
Storage temperature: -20 - 60°C
Humidity: 0 - 80% RH, non-condensing
Minimum hardware requirements
- PC/Mac:
CPU: Intel® i3 Dual Core 2.8GHz or higher
RAM: 4GB or more
A USB-C or USB-A interface
- Smartphone: Android device with UVC support and USB-C interface
Supported operating systems
Windows 10 and later (Windows 7 requires driver installation)
Mac OS X 10.13 and later
Android 5.x and later or iOS 10.1 and later, with Bluetooth 4.2 or higher that supports Bluetooth Low Energy (BLE)
Physical
Construction: Metal
Dimensions: 13.00 x 15.18 x 4.25 cm (5.12 x 5.98 x 1.67 in.)
Weight: 0.68 kg ( 1.5 lb )
