FS173-S4K-CO

More Auxiliary Functions
More professional functions assist users to accurately exposure and focus, when shooting, making and playing movies/ videos.

Full HD Resolution
Broadcast quality, see every little detail in massive Full HD quality!
Experience Full HD 1080P, 16.7 million color images, more clearer and sharper details, showing powerful color display capabilities, what you see is truly what you get! Let pre-production and post production more accurate. 17.3 inch large size, allows you to see every pixel.

True Color- Professional Color Calibration
SEETEC uses the professional Rec.709 HD color standard, and uses the color calibration technology, with the professional instrument calibration at the factory, it can achieve monitor calibration efficiently and get accurate color reproduction easily, do not distort the color, show the real image when you shooting video.

Accurate Color Reproduction
SEETEC monitor support ITU standards and HD video Rec.709 standard consistent color space, advanced image processing technology, so that the image clearly presented, the color is extremely natural, to ensure accurate color reproduction, to reproduce the physical nature of shooting, enabling users to accurately evaluate the quality of various input video signals.

Innovation OSD Operation
Switch signals quickly: VIDEO, DVI, HDMI, SDI
Four assignable shortcut keys: F1, F2, F3 and F4 for fast access to the functions you needs, Peaking, Pixel to Pixel, Camera Mode, Center Marker, Screen Marker and other functions by mean of push button.
Four rotary encoder switches: immediate access to Menu, Saturation, Brightness, Contrast, Focus, Camera Mode.

Professional Monitoring
Broadcast quality SD, HD and 3G monitoring!
SEETEC FS173-S4K is an incredibly high quality monitor that''s versatile enough to be used from the broadcast facility, mobile live production or on set for feature film production! The monitor comes with 3G/HD/SD-SDI, HDMI, Audio, Video, RS485, DVI-I inputs. Multiple input formats to meet all HD, SD, analogue video signal input and display demand Professional functions set.

Innovative Designed TALLY Optional
Innovative designed tally function optional can not only tell the photographer being recording status, also make you experience that professional technique of TV recording you the convenience for your creation.

Hassle-free Power
Monitoring anywhere you need it!
We''ve made it easy to power the monitor. The FS173-S4K can be powered in two ways: with an DC adapter or lithium batteries. The FS173-S4K has a flexible battery system that supports V battery plate (standard), Anton Bauer battery plate of your choice.

Stability and Reliability
Incredibly rugged design
Machined aluminum design that''s built to last! The full metal shell not only make the product more solid and durable, but also solve the problem of heat dissipation.

Display Specifications
Screen Size 17.3"
Color Depth 16.7M
Resolution 1920×1080 pixels
Dot pitch 0.1989(H)×0.1989(V) mm
Aspect Ratio 16:9
Brightness 300cd/m²
Contrast Ratio 700:1
Backlight LED
Viewing Angle 89°/89°(L/R) 89°/89°(U/D)

Input
1 X BNC 3G-SDI
1 X HDMI HDMI
1 X Video Video
2 X RCA Audio(L/R)
1 X DVI-I DVI-I
1 X RS485 RS485

Output
1 X BNC 3G-SDI
1 X HDMI HDMI
1 X Video Video
1 X RS485 RS485

Audio
Audio Stereo Headphone
Speaker

SDI Support Format
480i/576i
720p(60/59.94/50/30/29/25/24/23.98)
1080i(60/59.94/50)
1080p(60/59.94/50/30/29.97/25/24/24sF/23.98/ 23.98sF)

HDMI Support Format
480i/576i/480p/576p
1080i (60/59.94/50)
720p (60/59.94/50/30/29/25/24/23.98)
1080p (60/59.94/50/30/29.97/25/24/24sF/23.98/ 23.98sF)
4K UHD 3840×2160p (30/29.97/25/24/23.98Hz), 4096×2160p (24Hz)

General
Input Voltage DC9-24V
Power Consumption =27W
Working Temperature -10°C~50°C
Storage Temperature -20°C~60°C
Unit Size 425L×284H×35.7D mm (W/O stand feet)
Unit Weight 3.2kg

Advanced Features
* UMD and Text-Tally Display (TSL 3.1/4.0 Protocol)
* Peaking Focus Assist(Red highlight over parts of the monochrome image in focus)
* Center Marker
* Screen Marker (80%,85%,90%,93%,96%,2.35:1)
* Image Freeze
* Image Flip (H, V, H/V)
* Camera Mode
* Pixel-to-Pixel (Nonsupport in 4K input)
* Check Field (Red,Green,Blue,Mono)
* Zoom All (Nonsupport in 4K input)
* U/D & L/R Zoom (Nonsupport in 4K input)
* Aspect Ratio (Nonsupport in 4K input)
* Custom Color Temperature
* Built-in LED tally indicators optional

1 × Mini HDMI Cable
1 × V-Mount Battery Plate
1 x 3A Power Adapter
1 × Tally Kit optional
2 × Feet
1 × Operation Manual
