3GDA-R0

Name: 3GDA-R0
Brand: AJA
SKU: 3GDA-R0
Price: 1122299 NGN
Availability: OutOfStock

AJA

1x6 3G/HD/SD-SDI Reclocking Distribution Amplifier

go to the technical sheet

₦ 1,122,299.00

₦ 1,043,999.00 VAT excl.

Available in 11 days

Manuale: Download

Manufacturer: go to website

Not sure if this is the right product for you? Talk to a consultant

Product description
Specifications

The 3GDA 1x6 3G/HD/SD-SDI Reclocking Distribution Amplifier from AJA accepts and automatically detects (1) 3G HD-SDI, HD-SDI, or SDI input signal and distributes it to (6) separately buffered outputs. Input signals are reclocked and equalized before being transmitted. All ancillary data in the signal is passed from the input to the outputs.

3G HD-SDI, HD-SDI & SDI Distribution
Use this unit to distribute (1) 3G HD-SDI, HD-SDI, or SDI signal to up to (6) outputs.

Signal Integrity
All signals are reclocked and equalized before being transmitted to the separately buffered outputs.

Download

Manuale

Download (407.42KB)

Input (1) HD-SDI, SDI (SMPTE 259/292/296/424) on BNC connector
Output (6) 3G HD-SDI, HD-SDI, SDI on BNC connectors
Formats 3Gb, 1.5Gb, 270Mb auto-select
Power +5 to 18VDC, regulated, 3W (power supply required)
Dimensions (HxWxD) 1 x 5.8 x 2.4" (25 x 131 x 61mm)
