SC5C0N4 HDMI

Video / audio capture box with 4 × HDMI - H.264 input

Max. FPS
1920×1200p@60/50fps in - 1920×1200p@30/25fps out
1920×1080p@60/50fps in - 1920×1080p@60/50fps out

Recording Mode Hardware Compression, Real-Time Mode

Dimension 167.65×101.02 ( mm )

Interface PCIe×4 ( Gen2 )

Video Input 4×HDMI

Display Video Format YV12, NV12, YUY2, RGB24, RGB32

Video RAW Data Resolution
1920×1200p@30/25/24fps
1920×1080p@60/50fps
1920×1080p@30/25/24fps
1920×1080i@60/50fps
1280×720p@60/50fps
1280×1024p@60fps
1280×960p@60fps
1024×768p@60fps
800×600p@60fps
640×480p@60fps
720×480p@60fps
720×576p@50fps
720×480i@60fps
720×576i@50fps

Recording Video Format H.264 ( Hardware Compression )

Recording Video Resolution
1920×1200p@30/25/24fps
1920×1080p@60/50fps
1920×1080p@30/25/24fps
1920×1080i@60/50fps
1280×720p@60/50fps
1280×1024p@60fps
1280×960p@60fps
1024×768p@60fps
800×600p@60fps
640×480p@60fps
720×480p@60fps
720×576p@50fps
720×480i@60fps
720×576i@50fps

Audio Input 4×HDMI Embedded Audio

Audio Format Stereo / 16-bit / 32000 ~ 48000Hz

SDK
Support API : DirectShow, V4L2, Ffmpeg, Gstreamer
Support Language : C++, C#, .NET, Visual Basic, Qt, Delphi

System Requirement
OS Support Windows 7 / Windows 8 / Windows 8.1 / Windows 10
Linux 2.6.14 or Higher ( 32-bit and 64-bit )
