DeckLink SDI 4K

DeckLink SDI Specs
================

SDI Video Input 1 x 10 bit SD/HD switchable.
SDI Video Output 1 x 10 bit SD/HD switchable.
SDI Audio Input / Output: 8 Channels embedded in SD and HD.

Sync Input 1 x sync input. Blackburst in SD, 720p50, 720p59.94, 1080i50 and 1080i59.94 formats or Tri-Sync in any HD format.
Device Control Sony™ compatible RS422 deck control ports. Serial ports TxRx direction reversible under software control.
SD Format Support 625/25 PAL, 525/29.97 NTSC and 525/23.98 NTSC
HD Format Support 720p50, 720p59.94, 720p60, 1080PsF23.98, 1080p23.98, 1080PsF24, 1080p24, 1080PsF25, 1080p25, 1080PsF29.97, 1080p29.97, 1080PsF30, 1080p30, 1080i50, 1080i59.94 and 1080i60
SDI Metadata Support VITC read for 3:2 pulldown removal.
VANC capture and playback using up to 3 lines of video in file. HD RP188. Closed captioning
Audio Sampling Television rate of 48kHz and 24 bit.
Video Sampling 4:2:2
Color Precision 10 bit
Multiple Rate support SDI video connections are switchable between standard definition and high definition. SDI switches between 270 Mb/s standard definition SDI and 1.5 Gb/s HD-SDI.


Standards
================
HD Format Support 1080PsF23.98/24, 1080i50, 1080i59.94, 720p50 and 720p59.94.
SD Format Support 625/25 PAL, 525/29.97 NTSC and 525/23.98 NTSC.
SDI Compliance SMPTE 259M, 292/296M.
Video Sampling 4:2:2 4:2:2
Color Precision 4:2:2 10-bit 4:2:2 10-bit
Color Space 4:2:2 YUV 4:2:2 YUV
SDI Metadata Support VITC read for 3:2 pulldown removal.
VANC capture and playback using up to 3 lines of video in file. HD RP188.
Audio Sampling Television rate of 48kHz at 24 bit.
Card type PCI Express 1 lane, compatible with 1,4,8 and 16 PCIe slots.


Processing
================
Colorspace Conversion Hardware based real time.
HD Down Conversion HD to SD on video capture or video playback
HD Up Conversion SD to 720HD or 1080HD on video capture
Cross Conversion 720HD to 1080HD on video capture
Real Time Effects Apple Final Cut Pro™ internal effects. Adobe® Premiere Pro® Mercury Playback Engine effects. Avid Media Composer 6™ internal effects

Extras
================
Software Included Media Express, Disk Speed Test, LiveKey, Blackmagic System Preferences and Blackmagic driver on Mac OS X. Media Express, Disk Speed Test, LiveKey, Blackmagic Control Panel and Blackmagic driver on Windows 7. Media Express, Blackmagic Control Panel and Blackmagic driver on Linux
Physical Installation PCI Express 1 lane, compatible with 1, 4, 8, 16 lane PCI Express slots. Please see the full system requirements for Mac OS X and Windows 7. Mac OS X systems require an Intel-based Mac Pro computer
