Fiber Bridge 10 12G

Middle Things Fiber Bridge 10 12G, Supports 3G, 6G, 12G Signals, 10/100/1000 Mb/s Full/Half Duplex

The Fiber Bridge 10 splits a Neutrik opticalCON MTP® 24 fiber cable into 10 different OpticalCON Duo pairs + 2 LAN, and vice versa (reversible).

Stage box with reversible design
The Fiber Bridge 10 allows you to have only one cable running from the control room to the stage.
On the stage, the Fiber Bridge 10 acts as a stage box that splits the Neutrik opticalCON MTP® 24 fiber cable into 10 different OpticalCON Duo pairs + 2x LAN, and vice versa.
You can also use it in reverse and merge 10 OpticalCON Duo pairs + 2x LAN into one single opticalCON MTP® 24 fiber cable.

Can run with zero power
The Fiber Bridge is a passive splitter, meaning that no power is required to operate it.
However, if you plan to use the LAN connections, you need to provide +12V DC power using the barrel jack connector.

Rugged fiber connector
The opticalCON MTP® 24 connector makes the Fiber Bridge compatible with the rugged opticalCON MTP® 24 cable drums by Neutrik, designed for field use and tough handling.
The connector has a built-in automatic shutter that protects the 12 fiber cores as soon as the cable is disconnected.
