VersaStreamer HDMI
VersaStreamer HDMI
Previous keyboard_arrow_left
Next keyboard_arrow_right
VersaStreamer HDMI
VersaStreamer HDMI

VersaStreamer HDMI

Videon

Streaming Encoder/Decoder (HDMI)
go to the technical sheet
€ 1.240,44

€ 1.153,90 VAT excl.

Available in 19 days
Not sure if this is the right product for you? Talk to a consultant
Simultaneously stream up to 1080p H.264 video to three web destinations such as Facebook, YouTube, Twitch, Amazon Web Services, and others with the VersaStreamer Streaming Encoder/Decoder from Videon. The VersaStreamer has one HDMI input with a maximum resolution of 1080p60, it encodes up to 1080p30 for RTMP streaming, and outputs up to 1080p60 over its HDMI output.

The compact encoder/decoder features a 3.5mm audio input and supports embedded HDMI audio up to 320 kb/s, 48 kHz. It can record the stream over its two USB 2.0 ports using external USB media, simultaneously encoding and decoding while it streams over the network via 10/100/1000 Ethernet. The unit is managed by a simple web interface, and it also supports API configuration for third-party integration. On the front of the unit, a Stream action button allows you to begin your stream instantly, rather than having to connect to the web interface first.

Simultaneous RTMP/RTMPS streaming to three online platforms such as Facebook, YouTube, Twitch, Amazon Web Services, and others; supports RTSP, Unicast, Multicast, and HLS
Input and decode H.264 video up to 1080p60, encode up to 1080p30, at a maximum bit rate of 30 Mb/s
One HDMI input and one HDMI output
MPEG-4 AAC-LC audio encoding
Local recording via two USB 2.0 ports while streaming; FTP/sFTP upload; supports FAT32 and EXT4 file systems
Simultaneous encoding and decoding
Use the REST API to integrate with third-party controllers
Simple web management interface

Video Input Connectors 1 x HDMI v1.4a
Video Output Connector 1 x HDMI v1.4a
Audio Input 1 x 1/8" / 3.5 mm Analog
Embedded HDMI
External Recording Output 2 x USB 2.0
Network Connectors 1 x RJ45 10/100/1000 Ethernet
Streaming Protocols 3 x RTMP/RTMPS Simultaneous
RTSP
2 x Unicast (RTP over UDP, Raw UDP) Simultaneous
Multicast (RTP over UDP, Raw UDP)
HLS
Recording MP4, MPEG-TS via USB
sFTP/FTP Upload
Video Codec H.264, Baseline, Main, High
Bit Rate 250 kb/s to 30 mb/s
Bit Rate Control Variable, Constant
Audio Encoding Format: MPEG-4 AAC-LC in ADTS
Rates: 64, 96, 128, 192, 256, 320 kb/s
Encode Sampling Frequency: 32, 44.1, 48 kHz
Audio Decoding Formats: MPEG-1-Layer 2, MPEG-2/MPEG-4 AAC in ADTS/LOAS
Decode Sampling Frequency: 48 kHz
Input Resolutions 1080p: 60, 59.94, 30, 29.97, 25
1080i: 60, 59.94, 50
720p: 60, 59.94, 50
Encoding Resolutions 1080p: 30, 29.97, 25
1080i: 60, 59.94, 50
720p: 60, 59.94, 50
540p, 480p, 360p, 270p, 180p: Same as Source
Output Resolutions 1080p: 60, 59.94, 30, 29.97, 25
1080i: 60, 59.94, 50
720p: 60, 59.94, 50
576p50
480p: 60, 59.94
Power Input 12 VDC, > 15 W
Dimensions 1.8 x 6.5 x 6.2" / 4.6 x 16.5 x 15.7 cm
Weight 1.12 lb / 508 g
