Ultra Stream HDMI
Magewell
The HDMI input can accept UHD and DCI 4K signals up to 60 fps, so streaming from PCs or game consoles that support 4K output doesn't require any other hardware. Use the HDMI loop output to view the unaffected input signal at its full resolution. Internally, the Ultra Stream HDMI will downscale it appropriately for streaming and/or recording. If you like to have live audio over your streams and recordings, use the 3.5mm input jack to plug in a mic and the other 3.5mm jack to monitor on headphones.
Magewell Ultra Stream HDMI Specs
Inputs HDMI: 1 x HDMI type A, v1.4a
Microphone: 1 x 3.5 mm
Outputs HDMI: 1 x HDMI type A, loop output
Headphones: 1 x 3.5 mm
Other I/O Storage: 1 x USB 2.0 Type-A
Ethernet: 1 x RJ45
Resolution Support Input: Up to 4096 x 2160 at 30 fps (4:4:4, 4:2:2 sampling) or 60 fps (4:2:0 sampling)
Recording: Up to 1920 x 1080 at 60 fps
Frame Rate Support Input: 60/60i/30/25
Recording: 60/50/30/25/24/15
Sampling Input: 12/10/8-bit 4:4:4, 4:2:2, 4:2:0
Recording: 8-bit, 4:2:0
Wireless Connectivity Wi-Fi: IEEE 802.11 a/b/g/n/ac
Bluetooth: 4.0 BLE
Power Input 1 x Coaxial, 5 VDC, 2 A
Power Consumption 6 W (max)
Environmental Operating Temperature: 32 to 104°F / 0 to 40°C
Storage Temperature: -4 to 158°F / -20 to 70°C
Relative Humidity: 5-90%, non-condensing
Dimensions 3.7 x 3.7 x 1.1" / 94 x 94 x 29 mm
Packaging Info
Package Weight 0.9 lb
Box Dimensions (LxWxH) 6.9 x 4.7 x 0.86"
