VM-4UX

Inputs: 1 SMPTE 259M (SD-SDI), 292M (HD-SDI), 344M (ED-SDI), 424M (3G HD-SDI), ST-2081 (6G-SDI) and ST-2082 (12G-SDI) compliant serial video, 75? on a BNC connector
Outputs: 4 equalized and reclocked SMPTE 259M (SD-SDI), 292M (HD-SDI), 344M (ED-SDI), 424M (3G HD-SDI), ST-2081 (6G-SDI) and ST 2082 (12G-SDI), outputs 75? on BNC connectors
Cable Equalization Reach: 12Gbps: Up to 80m (260ft), 3Gbps and 6Gbps: Up to 100m (330ft), 1.5Gbps: Up to 200m (660ft), SD: Up to 300m (980ft), Note: The above specs apply when using Kramer cables
Video: Up to 4K@60Hz (4:2:2) 30bpp resolution, 270Mbps to 12Gbps data rate
Maximum output level: 800mVpp /75ohm
Coupling: AC
Standards Compliance: SMPTE 259M (SD-SDI), 292M (HD-SDI), 344M (ED-SDI), 424M (3G HD-SDI), ST-2081 (6G-SDI), ST-2082 (12G-SDI)
Power Consumption: 5V DC, 250mA
Power Source: 5.2V/4A
Enclosure: Tools size, Aluminum type
Cooling: Convection ventilation
Operating Temperature: 0° to +40°C (32° to 104°F)
Storage Temperature: -40° to +70°C (-40° to 158°F)
Humidity: 10% to 90%, RHL non-condensing
Included Accessories: Power supply, mounting bracket, 2 male BNC 75? terminators
Product Dimensions: 12.00cm x 7.15cm x 2.44cm (4.72" x 2.81" x 0.96" ) W, D, H
Product Weight: 0.2kg (0.4lbs) approx.
Shipping Dimensions: 49.00cm x 18.60cm x 58.80cm (19.29" x 7.32" x 23.15" ) W, D, H
Shipping Weight: 0.7kg (1.5lbs) approx.
