Blackmagic

9338716008210
Blackmagic Design Studio Camera 4K G2 12G-SDI, HDMI & 10G Ethernet Video I/O
go to the technical sheet
₦ 3,926,275.00

₦ 3,652,349.00 VAT excl.

Available 1 unit in 4 Days
Datasheet: Download
Not sure if this is the right product for you? Talk to a consultant
Blackmagic Design Studio Camera 4K G2 12G-SDI, HDMI & 10G Ethernet Video I/O - CINSTUDMFT/G24PDFG2

Made to work seamlessly with powerful SDI video switchers, the Blackmagic Design Studio Camera 4K Pro G2 now offers live streaming plus pro connections like 12G-SDI and 10GbE Ethernet.
The Ethernet connection enables you to set up a SMPTE-style workflow using a more affordable single-cable setup with PoE (power over ethernet) and the 12G-SDI output and program return provides camera control, talkback, and tally functions.
This latest 4K Pro model retains features like a 7" touchscreen monitor, HDMI output, Blackmagic Raw recording, HDR support, XLR audio, and Micro Four Thirds lens mount from its predecessor.

Micro Four Thirds Lens Mount
Capture up to UHD 4K 3840 x 2160p60
Live Streaming
12G-SDI, HDMI & 10G Ethernet Video I/O
Affordable Single-Cable PoE Workflow
7" High-Brightness HDR Touchscreen LCD
Record to External USB Type-C Disks
Records Blackmagic Raw, Up to 25,600 ISO
12G-SDI, HDMI & 10G Ethernet Video I/O
XLR & 3.5mm Audio Input, Built-In Mics

H-FS45150EKA
Panasonic

H-FS45150EKA

₦ 430,590.00 VAT included
Available 2 unit in 4 Days
H-PS14042E-K
Panasonic

H-PS14042E-K

₦ 654,351.00 VAT included
Available in 14 days
H-HS043E-K
Panasonic

H-HS043E-K

₦ 656,985.00 VAT included
Available in 24 days
H-FS35100E-K
Panasonic

H-FS35100E-K

₦ 618,823.00 VAT included
Available 1 unit in 4 Days
H-PS45175E-K
Panasonic

H-PS45175E-K

₦ 772,709.00 VAT included
Available 2 unit in 4 Days
H-ES045E
Panasonic

H-ES045E

₦ 1,305,963.00 VAT included
Available 2 unit in 4 Days
H-H025E-K
Panasonic

H-H025E-K

₦ 336,474.00 VAT included
Available 1 unit in 4 Days
H-FSA100300E
Panasonic

H-FSA100300E

₦ 1,103,540.00 VAT included
Available in 14 days
H-HS030E
Panasonic

H-HS030E

₦ 578,833.00 VAT included
Available in 14 days
H-NS043E
Panasonic

H-NS043E

₦ 2,595,963.00 VAT included
Available 1 unit in 4 Days
H-F007014E
Panasonic

H-F007014E

₦ 1,642,491.00 VAT included
Available in 14 days
H-FS12060E
Panasonic

H-FS12060E

₦ 745,726.00 VAT included
Available 2 unit in 4 Days
H-E08018E
Panasonic

H-E08018E

₦ 1,992,350.00 VAT included
Available 1 unit in 4 Days
H-ES35100E
Panasonic

H-ES35100E

₦ 2,027,879.00 VAT included
Available in 14 days
H-X012E
Panasonic

H-X012E

₦ 2,272,818.00 VAT included
Available in 14 days
MBSPEF-m43-BT9
Metabones

MBSPEF-m43-BT9

₦ 1,423,783.00 VAT included
Available in 24 days
MBSPEF-m43-BTB
Metabones

MBSPEF-m43-BTB

₦ 1,511,986.00 VAT included
Available in 24 days
MBSPEF-m43-BT8
Metabones

MBSPEF-m43-BT8

₦ 1,410,614.00 VAT included
Available in 14 days
MTB4M43
MTF

MTB4M43

₦ 786,146.00 VAT included
Available in 19 days
MBSPEF-m43-BTA
Metabones

MBSPEF-m43-BTA

₦ 1,511,986.00 VAT included
Available in 24 days
MTB4S16M43
MTF

MTB4S16M43

₦ 3,909,344.00 VAT included
Available in 19 days
MS260
Plantronics

MS260

₦ 431,934.00 VAT included
Available in 49 days
MS250
Plantronics

MS250

₦ 385,333.00 VAT included
Available in 49 days
Focus Demand
Blackmagic

Focus Demand

₦ 525,244.00 VAT included
Available 4 unit in 4 Days
Zoom Demand
Blackmagic

Zoom Demand

₦ 530,565.00 VAT included
Available 2 unit in 4 Days
MVR901EPLA
Manfrotto

MVR901EPLA

₦ 785,501.00 VAT included
Available in 14 days

Download

Datasheet

Download (724.51KB)

Sensor Resolution: Not Specified by Manufacturer
ISO Sensitivity: 100 to 25,600
Gain: 0 to 18 dB
Sensitivity:
f/11 at 2000 lux 89.9% Reflectance (UHD 4K60)
f/12 at 2000 lux 89.9% Reflectance (UHD 4K60)
Signal-to-Noise Ratio: 63 dB
Lens Mount: Micro Four Thirds
Shutter Speed: 1/5000 to 1/24 Second
Built-In ND Filter: None
Built-In Microphone Type: Stereo
Broadcast System Compatibility: NTSC, PAL
CCU I/O None
Video I/O:
1 x BNC (12G-SDI) Input
1 x BNC (12G-SDI) Output
1 x HDMI Output
Audio I/O:
2 x XLR 3-Pin Mic/Line (+48 V Phantom Power) Input on Camera Body
1 x 1/8" / 3.5 mm TRS Stereo Microphone Input
1 x 1/8" / 3.5 mm TRRS Headphone/Mic Input/Output
1 x XLR 5-Pin Intercom Input/Output
Other I/O:
1 x RJ45 (Ethernet) Control/Data/Monitor/Video Input/Output
2 x USB-C (USB 3.2 / 3.1 Gen 1) Data/Video Input/Output
Raw Recording:
Blackmagic RAW 10-Bit
3840 x 2160 at 23.98/24.00/25/29.97/50/59.94/60 fps [26 to 190 Mb/s]
Audio Recording
ProRes: 2-Channel 24-Bit 48 kHz LPCM Audio
Display Type: Fixed Touchscreen LCD
Size: 7"
Resolution: 1920 x 1200
Power I/O:
1 x XLR 4-Pin (12VDC) Input
1 x Barrel (12VDC) Input
Power Consumption: 46 W
Operating Temperature: 32 to 104°F / 0 to 40°C
Storage Temperature: -4 to 113°F / -20 to 45°C
Operating Humidity: 0 to 90%
Accessory Mount: 2 x 1/4"-20 Female
Tripod Mount: 3/8"-16 Female
Dimensions:
10.77 x 6.68 x 6.59" / 27.36 x 16.97 x 16.74 cm (Without Protrusions)
Weight: 3.71 lb / 1.68 kg

Blackmagic Design Studio Camera 4K G2
Sun Hood
Turret Dust Cap
Universal Power Supply with International Socket Adapters
15mm LWS Tripod Mount
Tally Decal Set
