SLXD24DESM58-J53

System
Wireless Transmission: Digital UHF
Number of RF Channels : 1760
Included Transmitters: 2 x Handheld
Diversity : True Digital Diversity
RF Bandwidth: 44 MHz
Frequency Step Size : 25 kHz
RF Channel Scanning : Auto-Scan
Max Operating Range : 328'' / 100 m
Max Systems per Setup: 32
Sample Rate/Resolution : 24-Bit
Latency : 3.2 ms
Dynamic Range: 120 dBA (Typical)
Encryption : None

Receiver
Form Factor: Rackmount
Mounting Options: Rackmount (with Included Hardware)
Rackmount Size : 1 RU (Full Rack)
Antenna : 2 x 1/4 Wave External, BNC (Rear-Mount)
Number of Audio Channels: 2
Audio I/O : 2 x XLR 3-Pin Male Balanced Mic/Line Output
2 x 1/4" TRS Female Balanced Output (Lockable)
Gain Range: 0 to +21 dB (3 dB Steps)
Pad : 30 dB
Audio Output Level: -18 to +42 dB (Balanced, Unbalanced)
Phantom Power Protection: On 1/4", XLR Outputs
Frequency Response : 20 Hz to 20 kHz +1/-2 dB (Dependent on Mic)
Network I/O : 1 x RJ45 (10/100 Mb/s)
Network Protocols: DHCP, Manual IP
Impedance : 1/4" Output:
1.3 Kilohms (Balanced)
670 Ohms (Unbalanced)
XLR Output:
400 Ohms (Balanced)
150 Ohms (Balanced)
Adjacent Channel Isolation: >70 dB
Spurious Rejection: >75 dB
Power Requirements: AC/DC Power Adapter
AC/DC Power Adapter: 15 VDC at 600 mA, Center-Positive (Included)
AC Input Power : 100 to 240 VAC, 50 / 60 Hz
Display & Indicators: LCD (AF Level, Channel, Group, RF Level, Transmitter Battery Status)
Housing : Steel
Operating Temperature: 0 to 122°F / -17 to 50°C
Storage Temperature : -20 to 165°F / -28 to 73°C
Dimensions : 15.5 x 1.7 x 6" / 393 x 42 x 152 mm
Weight : 3.1 lb / 1.4 kg (without Antenna)

Transmitter 1
Transmitter
Form Factor: Handheld
RF Output Power: 1 / 10 mW
Audio I/O : None
Pad: None
Muting: None
Audio Input Level : 8.2 dBV
Auto-Level Control : No
Gain Range : 0 +21 dB
Signal Processing: None
Frequency Response : 20 Hz to 20 kHz (Dependent on Mic)
Sync Method : IR
Antenna : Internal Single-Band Helical
Power Requirements: Battery
Battery Type : 2 x AA (Included)
1 x Shure SB 903 (Not Included)
Battery Charging Time: 1.25 to 5.5 Hours
Approx. Battery Life : 8 Hours (Lithium Shure SB903)
8 Hours (Alkaline)
USB/Lightning Connectivity: None
Display & Indicators : LCD (Battery Status, Channel, Group, Power)
Housing : Aluminum
Operating Temperature: 0 to 122°F / -17 to 50°C
Storage Temperature : -20 to 165°F / -28 to 73°C
Dimensions : 1.5 x 0.3" / 37.1 x 6.9 mm
Weight : 5.2 oz / 147 g

Microphone
Form Factor: Handheld Capsule
Sound Field: Mono
Capsule : Dynamic
Polar Pattern: Cardioid
Frequency Range : 50 Hz to 15 kHz
Sensitivity : -54.5 dBV/Pa
CMRR : None
Diameter: 1.97" / 50 mm

General
Packaging Info
Package Weight : 9.75 lb
Box Dimensions (LxWxH) : 17.7 x 13.9 x 4.5"
