XDA-QS5400RK

Name: XDA-QS5400RK
Brand: Yamaha
SKU: XDA-QS5400RK
Price: 4400706 NGN
Availability: OutOfStock

Yamaha

Amplifier with MusicCast Multi-Room Streaming (4 Zones, 8 Channels)

go to the technical sheet

₦ 4,400,706.00

₦ 4,093,679.70 VAT excl.

Available in 19 days

Not sure if this is the right product for you? Talk to a consultant

Product description
Specifications

Yamaha Amplifier with MusicCast Multi-Room Streaming (4 Zones, 8 Channels)

Designed specifically for custom integration of complete home audio systems, the "QS" (Quad Streamer) features four audio streaming zones and 8 channels of high-performance audio amplification in an ultra-slim, 1U-high rack enclosure .
Expandable and extremely flexible, the QS is complete with a MusicCast multi-room audio system which allows for various synchronization configurations with home theater AV receivers, sound bars and Hi-Fi electronics.

- Designed for custom integration of a MusicCast multi-room audio system connected via Ethernet LAN within a rack or cabinet
- Streams to four audio zones per unit, expandable up to 32 zones with simultaneous synchronized group playback of up to 20 zones per group
- Eight channels of audiophile-quality Class D amplification assignable to any zone, bridgeable and 4 ohm supported, and complete with unique ground loop/hum-free circuitry
- Built-in support for Pandora®, Spotify® Connect, SiriusXM Internet Radio, TIDAL, Deezer, Napster and more, plus access to synced music libraries and external sources
- Easy control via the free MusicCast app and third-party control systems
- 1U rack width and height enclosure, removable rack supports and faceplate included

Ingenious Integration
Designed and conceived entirely for custom installation, the "QS" represents the definitive integrated solution to spread extraordinary sound in any room of the house.

Slim but Powerful
The QS covers four rooms of audio streaming and eight channels of audiophile-quality amplification, despite an incredibly slim 1U enclosure height design, perfect for optimizing installation within your precious rack cabinet.

Easy Expansion
Multiple QS units can be used to expand coverage to up to 32 zones with simultaneous synchronized group playback of up to 20 zones per group.
Additionally, the QS features four pre-out zones that allow pairing with the Yamaha XDA-AMP5400RK multi-room amplifier, for more power or additional speaker connections for installation in very large homes.
The pre-outs can also be used to connect powered subwoofers or subwoofer amplifiers.

Audiophile Quality Amplification
No traditional amplification, the QS uses ultra-efficient ICEpower integrated circuits to achieve eight channels of pure, dynamic and musical digital amplification at 50 watts per channel (8 ohms) with an extraordinary frequency response from 10 Hz up to 20 kHz (+0 /-3 dB) and a signal to noise ratio of 106 dB.
It supports 4 ohms at 100 watts per channel and is bridgeable to deliver 200 watts per channel (8 ohms).

Goodbye to Ground Loop Hums
The custom integrator's nightmare: ground loop hum, a typical and worrying side effect of connecting a large number of electronic devices inside a rack.
The QS solves the problem thanks to a cleverly engineered differential circuit.

Network Section
File Format: MP3 / WMA / MPEG-4 AAC, ALAC: up to 96 kHz / 24-bit, WAV / FLAC / AIFF: up to 192 kHz / 24-bit
Ethernet: Yes (2 terminals)
AirPlay: Yes

Audio
Channel: 8 channel (2 channel x 4)
Minimum Speaker load Capability: 4 ohm
BTL Connection: Yes
Speaker Output Terminal: 4 (Euroblock)
Preout Terminal: 4
Audio Input Terminal: RCA: 2 (CUT IN, AUX), USB: 4
Audio Output Terminal: RCA (2-ch through out): 2 (CUT IN, AUX)
Trigger In / Out: 0 / 4
Remote In / Out: 1 / 1
Chime: 4
Rated Output Power (1 kHz, 0.9% THD, 2ch driven): Normal (4 / 8 ohms): 90 / 50 W, Bridge (8 ohms): 100 W
Dynamic Power (20 Hz-20 kHz, 0.08% THD, 2ch driven, 20 ms burst): Normal (4 / 8 ohms): 80 / 40 W, Bridge (8 ohms): 150 W
Dynamic Power (1 kHz, 0.9% THD, 2ch driven, 20 ms burst): Normal (4 / 8 ohms): 100 / 50 W, Bridge (8 ohms): 200 W
Dynamic Power (1 kHz, 0.9% THD, All ch driven, 20 ms burst): Normal (4 / 8 ohms): 80 / 50 W, Bridge (8 ohms):170 W
Maximum Effective Output Power: [1-ch driven, 1 kHz, 10% THD] Normal (4 / 8 ohm): 130 / 65 W, Bridge (8 ohm): 260 W
Total Harmonic Distortion: [SP OUT, 20 Hz-20 kHz, 25 W, 8 ohm] 0.04%, [PRE OUT, 20 Hz-20 kHz, 1 V] 0.005%
Frequency Response: [1 kHz + 0 / -3 dB] PRE OUT NET / USB IN, AUX IN: 10 Hz-22 kHz, SP OUT NET / USB IN, AUX IN: 10 Hz-22 kHz
Signal to Noise Ratio: [PRE OUT NET / USB IN] 114 dB, [PRE OUT AUX IN] 108 dB, [SP OUT NET / USB IN] 106 dB, [SP OUT AUX IN] 104 dB
Rated Output Level / Output Impedance: [PRE OUT L / R, 1 kHz] 2.0 V / 470 ohm
Maximum Output Level: [PRE OUT L / R, 0.9% THD] 4.0 V
Maximum Input Signal: [PRE OUT L / R, 0.9% THD] 2.4 V
Gain: [SP OUT 1 V Input] 25.8 dB
Input Sensitivity: [1 W Power, 8 ohm] 150 mV, [MAX (50W) Power, 8 ohm] 1.0 V
Web Setup: Yes
Direct Mode: Yes
Monaural Downmix: Yes (stereo playback or monaural downmix selectable)
Compressed Music Enhancer: Yes
Volume Adaptive EQ: Yes
Volume Control: Support Terminals: PRE OUT / SP OUT, Range: Mute, -80 dB ~ 0 dB, Step: 0.5 dB
EQ Characteristics: [Bass] Variable Width: +6.0 dB ~ -6.0 dB / 0.5 dB step, Centre Frequency: 350 Hz, [Mid] Variable Width: +6.0 dB ~ -6.0 dB / 0.5 dB step, Centre Frequency: 1.1 kHz, [Treble] Variable Width: +6.0 dB ~ -6.0 dB / 0.5 dB step, Centre Frequency: 3.5 kHz
Bass Extension: Yes

General
Power Consumption: 130 W, [All Zone On] No Signal Condition: 40 W, [All Zone Off] Chime On: 18.2 W, Cut In Power On Enable: 18.2 W
Standby Power Consumption: Network Standby Off: 0.2 W, Network Standby On(1 Zone): 3.2 W, Network Standby On(All Zone): 6.0 W
Power Management (Auto Power Standby): 5 / 20 min, 2 / 4 / 8 / 12 hours selectable
Dimension (W × H × D) mm: [Table Top Mount with Adhesive Feet] 437 x 46 x 443 mm, 17-1/4" x 1-3/4" x 17-3/8", [Table Top Mount with Adhesive Feet and Faceplate] 437 x 46 x 453 mm, 17-1/4" x 1-3/4" x 17-7/8", [Rack Mount] 481 x 44 x 443 mm, 18-7/8" x 1-3/4" x 17-3/8", [Rack Mount with Faceplate] 481 x 44 x 453 mm, 18-7/8" x 1-3/4" x 17-7/8"
Weight: 6.3 kg, 13.9 lbs.
