Chronos 1.4 16GB Color Sensor
- New
₦ 27,968,941.00 VAT excl.
Camera
Imaging: 4096 x 2160 @ 1,397 FPS
Memory: 128GB
Record Time (in seconds): 5.5 (64GB), 11 (128GB) at max resolution
Backfocus: Field adjustable via included shim kit
IR Filter: 650nm, user removable
Display: 5" 800x480 capacitive touchscreen, 1000 nit daylight visible
Enclosure: Anodized CNC machined aluminum
Cooling: Active cooling, variable-speed fans
Dimensions: 188mm x 111mm x 53mm (7.40" x 4.37" x 2.08") w/o lens
Weight: 1.32 kg (2.91 lbs) without lens
Image Sensor
Resolution: 4096 x 2160 @ 1,397 FPS Maximum 128x32 @ 29,002 FPS Minimum
Speed: 11.8 Gigapixels per second
Dimensions: 20.74mm x 9.79mm (4/3" format, 10-Megapixel, 2x Crop Factor)
Pixel Pitch: 4.5um
Sensitivity (ISO): Color - ISO 100 to 400 Mono - ISO 200 to 800
Shutter: Electronic global shutter, 1/fps to 1us (1/1,000,000 s)
Dynamic Range: 11.3 stops (68 dB) in 12-bit mode
Bit Depth: 8-bit, 10-bit, or 12-bit User Selectable
Video Formats
Compressed: Standardized H.264 AVC, or H.265 HEVC MPEG-4 Video Files
Raw: Standard Adobe CinemaDNG raw files
Storage Devices: Internal 1 TB NVMe SSD, SD Card, USB-C SSD, or SMB/NFS network drives
Inputs/Outputs
Power Input: 12-24V 60W (5.5/2.5mm barrel jack, positive tip)
Network: Gigabit Ethernet via USB-C Adapter WiFi via USB-C Adapter
Trigger:3 trigger inputs/ frame strobe outputs (4-pin 3.5mm TRRS Connector) Adjustable input threshold 0 to 6.6V. Optional TRRS to BNC splitter cable accessory.
Video: HDMI output 4K @ 30 FPS or HD @ 60 FPS
USB: Dual USB Type C Ports USB-C Port 1: 3.2 Gen 1, 5 Gbps (PC or Peripheral) USB-C Port 2: 3.2 Gen 2x2, 20 Gbps (Peripheral, SSDs)
Software
Control: Desktop, iOS, and Android Apps coming soon. Connect via optional Ethernet or WiFi adapters.
Stream: Live or Playback Mode network streaming via RTSP stream.
APIs: HTTP REST Interface, Open-source codebase
Trigger Modes
End Trigger: Records until a defined delay after trigger
Toggle: Starts and stops with button press
Exposure Trigger: External signal sets synchronization frame rate
Shutter Gating: External signal sets the exposure synchronization and frame-rate
Frame Sync Output: Outputs a signal indicating its frame rate and exposure
Network Control
Network Control: Through control apps or REST API via optional Ethernet or WiFi adapters.
Recording Modes
Normal: Records into the ring buffer. Once a trigger occurs, video can be reviewed and saved.
Segmented: Video memory is divided into segments, each recording as in the Normal mode above. Number of segments is user selectable.
Gated Burst: Frames are captured while trigger is active
Environmental
Operating Temperature: 0 °C to +40 °C (32 °F to +104 °F)
Assistive
Focus Aid: Highlights sharp edges to aid focusing
Zebras: Rolling diagonal lines indicate clipped (overexposed) areas
Histogram: Graphically represent brightness and distribution of light in the image
Viewfinder Zoom: Zooms in to allow easier focusing
Overlay: Displays frame and time information on top of footage
