DMON-QUAD

4 x (3G/HD/SD)-SDI to HDMI Converters with 1 to 4 MultiViewer, Custom Layouts and 8 Channel Audio Meters

• Supports 3G level A and B on inputs and output, allowing
conversion between 3G level A and B
• Low cost (3G/HD/SD)-SDI 1 to 4 Multi-Viewer or
4 to 1 input multiplexer
• Custom Layouts with various standard layouts
• 16 Character UMD overlay per window with individual
enables, custom positioning and size
• 8 Channel Audio Metering overlay per window with
individual enables, custom positioning and size
• Horizontal and/or Vertical image flipping per window
• Audio ID overlay
• Tallies can be applied to either Tally Boxes (Default) or
Border
• Tally boxes allows for up to 4 Tallies per window
• Fast switching between inputs using Full-Screen scaling
• Selectable output format in both Full-Screen Multi-Viewer
mode
• Low latency buffering for each input allowing
non-synchronous inputs
• Linked (3G/HD/SD)-SDI and HDMI outputs
• 4 x (3G/HD/SD)-SDI inputs with auto detection
(26 Formats supported in total)
• Each window is independent of the others, allowing any
3G/HD/SD format of any frame rate to be displayed
simultaneously
• Variable aspect ratios per window
• In Pass-Through mode the selected input is passed
through to both the (3G/HD/SD)-SDI and HDMI outputs
• The DMON-QUAD is a truly portable converter, that
incorporates our easy to use LCD and button control
system. This gives you easy access to most of the amazing
features without using complicated LED/button control,
dip switches or having to carry around a computer to change
a simple setting.
• This unit also includes:
- GPI on RJ-45 connector for Tallies and Remote Switching
- RS422/485 on RJ-45 connector for Dynamic UMD and Tallies
- USB port for control and firmware updates
- Robust Aluminium box
- Metal Thread Locking DC Power Socket
- Power Supply, HDMI Cable and USB Cable
