Teranex Mini - SDI12 to Analog

Connections
SDI Video Input

1 x 12G-SDI SD/HD/2K/4K auto switching.
SDI Video Output

1 x 12G-SDI loop output.
HDMI

1 x HDMI 2.0 type A connector with support for 2160p60.
Analog Audio Output

2 channels professional balanced analog audio via XLR connectors. Right XLR can be configured for Timecode output.
AES/EBU Audio Output

4 channels professional 110O balanced digital audio via XLR connectors. Right XLR can be configured for Timecode output.
Multi Rate Support

Automatic switching between SD/HD/2K and 4K.
Updates and Configuration

USB or Ethernet.
Re-Clocking

Yes
Teranex Mini - SDI to HDMI 12G
Standards
SD Format Support

525/29.97 NTSC, 625/25 PAL.
HD Format Support

1280 x 720p50, 1280 x 720p59.94, 1280 x 720p60, 1920 x 1080i50, 1920 x 1080i59.94, 1920 x 1080i60, 1920 x 1080PsF23.98, 1920 x 1080PsF24, 1920 x 1080p23.98, 1920 x 1080p24, 1920 x 1080p25, 1920 x 1080p29.97, 1920 x 1080p30, 1920 x 1080p50, 1920 x 1080p59.94, 1920 x 1080p60.
2K Format Support

2048 x 1080PsF23.98, 2048 x 1080PsF24, 2048 x 1080PsF25, 2048 x 1080p23.98, 2048 x 1080p24, 2048 x 1080p25.
4K Format Support

3840 x 2160p23.98, 3840 x 2160p24, 3840 x 2160p25, 3840 x 2160p29.97, 3840 x 2160p30, 3840 x 2160p50, 3840 x 2160p59.94, 3840 x 2160p60, 4096 x 2160p23.98, 4096 x 2160p24, 4096 x 2160p25, 4096 x 2160p29.97, 4096 x 2160p30, 4096 x 2160p50, 4096 x 2160p59.94, 4096 x 2160p60.
SDI Compliance

SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 372M, SMPTE 424M-B, SMPTE 425M.
SDI Video Rates

SDI video connections are switchable between standard definition, high definition level B 3G-SDI, 6G-SDI and 12G-SDI.
SDI Video Sampling

4:2:2 and 4:4:4
SDI Audio Sampling

Television standard sample rate of 48 kHz and 24-bit.
SDI Color Precision

4:2:2 and 4:4:4
SDI Color Space

YUV and RGB
SDI Auto Switching

Automatically detects SD, HD or 12G-SDI.
HDMI Format Support

525/29.97 NTSC, 625/25 PAL, 1280 x 720p50, 1280 x 720p59.94, 1280 x 720p60, 1920 x 1080i50, 1920 x 1080i59.94, 1920 x 1080i60, 1920 x 1080p23.98, 1920 x 1080p24, 1920 x 1080p25, 1920 x 1080p29.97, 1920 x 1080p30, 1920 x 1080p50, 1920 x 1080p59.94, 1920 x 1080p60, 2048 x 1080p23.98, 2048 x 1080p24, 2048 x 1080p25, 3840 x 2160p23.98, 3840 x 2160p24, 3840 x 2160p25, 3840 x 2160p29.97, 3840 x 2160p30, 3840 x 2160p50, 3840 x 2160p59.94, 3840 x 2160p60, 4096 x 2160p23.98, 4096 x 2160p24, 4096 x 2160p25, 4096 x 2160p29.97, 4096 x 2160p30, 4096 x 2160p50, 4096 x 2160p59.94, 4096 x 2160p60
HDMI Color Space

REC 601, REC 709
HDMI Color Precision

YUV 4:2:2 and RGB 4:4:4 in HD, 2K and 4K.
Software
Software Control

Mac OS X™ and Windows™ software upgrade via USB or Ethernet.
Internal Software Upgrade

Via included updater application.
Setting Control
Basic Settings Control

Mini Switches, USB and Ethernet via free software utility.
Optional Front Panel Control

Front mounted Smart Panel with LCD, rotary knob and six settings buttons.
Power Requirements
Power Supply

1 x built-in international AC power supply with IEC C14 inlet. IEC Power cable required. 90 - 240V AC Input.
Power Over Ethernet

Can be powered via 48V DC using PoE (power over ethernet).
Power Consumption

15 Watts
Operational Voltage Range

90 - 240V AC
Physical Specifications
Teranex Mini - SDI to HDMI 12G
Environmental Specifications
Operating Temperature

0°to 40°C (32° to 104°F)
Storage Temperature

-20°to 60°C (-4° to 140°F)
Relative Humidity

0% to 90% non-condensing
What''s Included

Teranex Mini - SDI to HDMI 12G

Software SD Card
Warranty

3 year Limited Manufacturer''s Warranty.
