PXW-Z280D2721 kit - Sony
- New
€ 5.024,07 VAT excl.
€ 5.539,37Sensor 1.0 Inch-type CMOS
Filter RGB Primary Colour Filter
Total pixels Approx. 13.4 MP
Effective pixels Approx. 8.29 MP (3840 x2160)
Image Processor DIGIC DV7
Gain Boost Function Yes, increases gain to 36dB,activated via user
assigned button
Sensitivity (PAL) f/13, 50.00P, 2000 lux, reflectance 89.9%
Minimum illumination (PAL) 50.00P/50.00i Approx. 2.5 lux
(1/50 second shutter speed)
25.00P Approx. 1.3 lux (1/25 second shutter speed)
Zoom ratio 15x optical, (30x Advanced Zoom Full HD)
Focal length
(35mm equivalent)
Approx. 25.5 to 382.5 mm Standard IS/IS Off
Minimum focus distance 10 mm at wide end, 60 cm across entire
zooming range
Max. Aperture f/2.8
Aperture blades 9 blades
Filter diameter 58mm
Image stabilization system Optical system (lens shift) + electronic stabilization
Dynamic, Standard, Powered, Off
ND filter 3 densities: turret switched, motor-driven.
ND 1/4, ND 1/16, and ND 1/64.
Zoom control Zoom rockers on body and handle;
Selectable manual zoom/focus ring on lens;
Wireless controller; Selectable High-Speed mode
available.
Zoom speed Variable or Constant speed Fast/Normal/Slow, 16
speed level settings
Focus control MANUAL: Lens ring and touchscreen point selection
(Focus Guide and Peaking assist functions), Focus
Preset.
AUTOFOCUS: Touchscreen AF point selection, Face
Detection and Tracking, Face Only AF.
(Continuous AF, AF-Boosted MF, AF Speed, AF
Response, AF Frame size)
Focus System Dual Pixel CMOS AF, Contrast AF, Eye AF,
EOS iTR AF X
Iris control Touchscreen, Auto, Lens ring
Digital zoom/Teleconverter 300x Digital Zoom, Digital Teleconverter (x1.5/x3/x6.
Not available when optical teleconverter used)
Type DIGIC DV7
Colour Sampling
XF-AVC: 4:2:2,
MP4: 4:2:2 or 4:2:0 H.265/4:2:0 H.264.
XF-AVC/MP4 Proxy files: 4:2:0
Bit depth XF-AVC/MP4 H.265: 10-bit.
MP4 H.264: 8-bit
XF-AVC/MP4 Proxy files: 8-bit
RECORDING
Video storage media SD/SDHC/SDXC card (2 card slots)
Type Class U3 V90 cards recommended
Recording time
(128GB Card, approx.)
XF-AVC: 410Mbps. 39 mins. 310Mbps, 51 mins.
260Mbps, 100 mins.
MP4/H.265: 225 Mbps, 71 mins. 170Mbps,94 mins. 135
Mbps,118 mins
MP4/H.264: 150 Mbps, 107 mins. 35 Mbps, 458 mins.
8Mbps, 2006 mins
Recording file system FAT32/exFAT
Internal recording format
(PAL)
XF-AVC (MXF) UHD: ALL-I/Long GOP. Full HD/Proxy
Files: Long GOP
MP4: H.265 UHD, Full HD
Simultaneous Recording Yes. Simultaneous recording, relay recording.
Different recording options possible on each
memory card
Recording frame rate (PAL) UHD
XF-AVC 422 10bit
3840 x 2160 (160 Mbps): 59.94P/ 29.97P/
23.98P/50.00P/ 25.00P
MP4 (HEVC/H.264) 422 10bit
3840 x 2160: 59.94P/ 29.97P/ 23.98P/50.00P/ 25.00P
Full HD, XF-AVC 422 10bit:1920 x 1080 (45 Mbps)
59.94P/ 59.94i / 29.97P/ 23.98P/50.00P/ 50.00i / 25.00P
120P, MP4 (HEVC/H.264) 422 10bit,1280 x 720
59.94P/ 29.97P/ 23.98P/50.00P/ 25.00P
External recording output,
12G-SDI/HDMI
3840 x 2160: 59.94p/50.00p/29.97p/25.00p/23.98p
1920 x 1080: 59.94p/50.00p/29.97p/25.00p/23.98p/
29.97PsF/25.00PsF 59.94i/50.00i
1280 x 720: 59.94p/50.00p
720 x 480: 59.94i
720 x 576: 50.00i
External monitoring Yes, 12G-SDI or HDMI . Simultaneous output available
High Frame Rate Yes, Up to 120P (FHD, 4:2:2/8-bit) including in 50.00Hz
mode. Simultaneous Audio Recording
Pre Record function Yes. 3 seconds
Special Recording Functions Frame Recording, Interval Recording
Still photos JPEG up to 3840x2160
(Still image resolution is dependent on the video
resolution)
Photo storage media SD Card (Slot B)
SHOOTING FUNCTIONS
EXPOSURE
Exposure metering Centre-weighted average or segment evaluative
(determined by shooting mode)
Fixed exposure (1/50 sec.)
Exposure compensation Highlight AE, Exposure lock, Auto backlight
compensation, Exposure compensation amount
shown as ±3 when locked or ±2 in AUTO
(±8 increments).
Exposure Lock Yes.
ISO Range/Setting ISO200 - ISO12,800. 1 Stop or 1/3 Stop increments
Gain Range Setting .-6.0dB - 21.0dB. Normal or Fine setting. Fine setting in
0.5dB steps.
SHUTTER SPEED
Control modes Auto, P, Tv, Manual
Shutter Angle Mode Yes, 360° to11.25°
Shutter speed (PAL) Up to 1/2000 Sec.
Slow Shutter (SLS, PAL) 50.00i/50.00P:1/4, 1/8, 1/12, 1/25 sec
25.00P: 1/3, 1/6, 1/12 sec
Clear (PAL) Yes,24.00Hz to 2003.17Hz
