General data
Article number S1934H-GY
Furniture color Light Gray
Type of employment Office
FlexScan line
EAN 4995047049227
S1934H-BK variant (Color: Black)
Screen
Diagonal [inches] 19
Diagonal [in cm] 48
Format 5: 4
Active display area (LxH) 375 x 300
Recommended resolution 1280 x 1024
Pixel pitch [mm] 0.29 x 0.29
Supported resolution 1280 x 1024, 1024 x 768, 800 x 600, 720 x 400, 640
x 480
IPS panel technology
Horizontal viewing angle
max.
178 °
Vertical viewing angle
max.
178 °
Representable colors 16.7 million colors (DVI, 8 bits), 16.7 million colors
(Display Port, 8 bit), 16.7 million colors (Dsub, 8 bit)
Maximum sRGB color space
Maximum brightness (typical) [cd / m²] 250
Maximum contrast 1000: 1
Typical response time [change
gray-gray]
14 ms
Max. Refresh rate [in Hertz] 61
LED backlight
Functionality
Representable colors / LUT 1.06 billion tones / 10 bits
HDCP support: Yes
Preset mode sRGB, Card, 2x customizable modes, DICOM
Menu OSD de, en, fr, es, it, se, ja, zh
Settings for brightness, contrast, gamma, EcoView functions, color saturation, color temperature, color mode,
color tone, signal input, resolution, audio source, smoothing, OSD menu, interpolation, volume
DisplayPort signal inputs (HDCP 1.3), DVI-D (HDCP 1.4), Dsub
DisplayPort video signals, DVI (TMDS), analog RGB
Automatic signal priority
of entry: Yes
Separate synchronization formats
3.5mm stereo chinch audio input
3.5 mm stereo chinch audio output
Built-in speakers: Yes
Electrical specifications
Typical energy consumption [watt] 9
Maximum consumption [watt] 21
Energy saving mode [
watt]
0.5
Power consumption Off [watt] 0
Auto-EcoViews: Yes
EcoView-Index: Yes
AC power 100-240 V, 50/60 Hz
Energy saving VESA DPMS, DVI-DMPM
Integrated power cable: Yes
Dimensions - Weight
Dimensions [mm] 405 x 407-507 x 205
Weight [kg] 5.6
Dimensions without pedestal [mm] 405 x 334 x 62
Weight without pedestal [kg] 3.8
Rotation (right / left) 35 °
Downward / backward inclination
up
0 ° / 30 °
Pivot function: Si 90 °
Height adjustment [mm] 100
VESA Standard mounting holes 100 x 100 mm
Certifications and standards
Certifications CE, CB, EPA Energy Star, TÜV / GS, TÜV / Ergonomics
(including ISO 9241-307), EPEAT 2018 (US), cTÜVus,
TÜV / S, EAC, PSE, FCC-B, CAN ICES-3 (B), RCM, VCCIB, CCC, RoHS, China RoHS, WEEE
Software and accessories
Supplied accessories Power cord, DVI-D signal cable - DVI-D,
Dsub signal cable - Dsub, audio cable, instructions of
quick consultation, EIZO LCD Utility Disk (incl. Manual)
Optional EIZO ScreenCleaner (For efficient cleaning of parts and
surfaces)
