ATEM156S

Name: ATEM156S
Brand: Seetec
SKU: ATEM156S
Price: 1641363 NGN
Availability: OutOfStock

Seetec

EAN: 6971863810256

Monitor 15,6" IPS, 1920x1080, 4K HDMI 4x 3G SDI in and output

go to the technical sheet

₦ 1,641,363.00

₦ 1,526,849.00 VAT excl.

Available in 14 days

Manufacturer: go to website

Not sure if this is the right product for you? Talk to a consultant

Multiple display mode(1P, PIP, 4P)
1920x1080 full HD IPS screen
Support 3D LUT Log to REC.709 and user 3D LUT upload (up to 36)
Support HDR monitoring
With Waveform, Vectorscope, RGB Histogram, Focus Assist, Monochrome etc. functions, can help you accurately exposure and focus every shot.
Stereo Earphone output
In quad split display mode, SDI audio can show 4 channels and 4 time codes
In single display mode, SDI audio can show 16 channels
Supports GPI control
In PIP/quad display mode can be switching signal freely
User custom menu saving function

Standard Accessory
2A DC Power Adapter
V-Mount Battery Plate
U-shaped Bracket
1.5M Mini HDMI Cable
1.5M BNC Cable
Sunshade
Operation Manual

the main difference compared to the ATEM156 - SEETEC model, is that these new "S" version models connect up to 4 3G SDI inputs and outputs
while the ATEM156 - SEETEC is with 4 HDMI inputs and outputs

Stands - Hardware - Tools Micro POV & Webcam

Manfrotto

MLTSA1001B

₦ 339,538.00 VAT included

Available in 14 days

Marshall

CV370

₦ 1,752,840.00 VAT included

Available in 19 days

Marshall

CV374

₦ 2,057,334.00 VAT included

Available in 19 days

Description: 15.6" 3D LUT Director Monitor
Model: ATEM156S
Screen size: 15.6" IPS
Resolution: 1920×1080 pixels
Display Colors: 16.7M colors 8bits (6-bit + Hi-FRC)
Gamut: 47% NTSC
Pixel pitch: 0.17925(W) x 0.17925(H) mm
Aspect Ratio: 16:9
Brightness: 200 cd/m²
Contrast: 800:1
Backlight: LED
Response Time: Tr + Tf=30ms
Viewing Angle: 85°/85°(L/R) 85°/85°(U/D)
Inputs: HDMI*1, SDI*4, RS458*1, DPI*1, USB*1
Outputs: SDI*4, RS458*1
Audio: 3.5mm Stereo Headphone, Speaker

SDI Support Format:
720p (60/59.94/50/30/29/25/24/23.98)
1080i (60/59.94/50)
1080p (60/59.94/50/30/29.97/25/24/24sF/23.98/23.98sF)
2048x1080i (60/59.94/50)
2048x1080p (60/59.94/50/30/29.97/25/24/23.98)

HDMI Support Format:
480i/576i/480p/576p
720p (60/59.94/50/30/29.97/25/24/23.98)
1080i (60/59.94/50)
1080p (60/59.94/50/30/29.97/25/24/23.98)

Power Consumption: =21W
Input Voltage: DC 12V
Operating Temperature: 0°C - 50°C
Storage Temperature: -20°C - 60°C
Unit Size: 372L×262H×28.4D (mm) (without bracket)
Unit Weight: 1.81kg (without bracket)
