MXC COMPACT 2CH SDI

MXC (Multi Cross Converter) is a software based multichannel video Encoder/Decoder suitable to be used for Contribution & Distribution purposes, able to convert various video inputs (such as SDI, NDI, SMPTE 2110, WebRTC, SRT, and IP) to various outputs.
It is available in different versions, with up to 9 channels, and can be delivered as a software or a turnkey rack appliance.
MXC includes features such as format conversion, aspect ratio adjustment, cropping and zooming, audio leveling, and channel reshuffling.
The user interface is configurable and can be used for multi view monitoring and configuration purposes.

MXC (Multi Cross Converter) is a software based multichannel video Encoder/Decoder suitable to be used for Contribution & Distribution purposes. MXC can convert any video inputs (such as SDI, NDI, SMPTE 2110, WebRTC, SRT, and IP) to various outputs, executing in the meantime format conversion, aspect ratio adjustment, cropping and zooming, audio leveling, and tracks reshuffling. A such unique blend of features turns MXC into an essential component in the Production Control Room, to manage Input and Output Contributions and heterogenous external feeds, and in the Master Control Room, to deliver your Program to the Distribution Network.

It is available in different versions, with 1, 2, 4 and 9 channels, and can be delivered as a software or a turnkey 1 RU appliance. The user interface is configurable and can be used for multi view monitoring and configuration purposes.


Rackmount 1RU workstation with SD/HD-SDI input and output board and connection manager software

Two of these workstations allow to buld a near zero latency bi-directional connection between two locations.
Suitable for conferences, conventions, live events when no-latency in communications is mandatory.

VIDEO INPUT: SD-SDI, HD-SDI, NDI, IP*
VIDEO OUTPUT: SD-SDI, HD-SDI, NDI, IP*

Conversion, upscaling, downscaling, crop, managing audio levels, fileds inversion.
Multivew GUI with audio meters

A suitable internet connection is required

* UDP/RTMP/RTSP/HTTP
