₦ 826,898.12 VAT excl.
Directional pattern: Supercardioid
Principle of operation: Pressure gradient
Cartridge type: Pre-polarized condenser
Frequency response: 20 Hz - 20 kHz
Effective frequency range ±2 dB, at 20 cm (7.9 in): 80 Hz - 15 kHz with 2 dB soft boost at 10-12 kHz
Sensitivity, nominal, ±3 dB at 1 kHz: 16 mV/Pa, -36 dB re. 1 V/Pa
Equivalent noise level, A-weighted: Typ. 23 dB(A) re. 20 µPa (max 26 dB(A))
Equivalent noise level, ITU-R BS.468-4: Typ. 35 dB (max. 38 dB)
Distortion, THD < 1%: 130 dB SPL RMS, 133 dB SPL peak
Dynamic range: Typ. 110 dB
Max. SPL, THD 10%: 135 dB SPL peak
Rated output impedance: From MicroDot: 30 - 40 O. From DAD4099-BC XLR Adapter: 100 O
Cable drive capability: Up to 300 m (984 ft) with DAD4099-BC XLR Adapter
Common mode rejection ratio (CMRR): > 60 dB from 50 Hz to 15 kHz with DAD4099-BC XLR Adapter
Power supply (for full performance):
- For wireless systems Min. 5 V - max. 10 V through DPA adapter
- With DAD6001-BC: P48 (Phantom Power). Will work from 12 V
Current consumption: Typ. 1.5 mA (microphone). 3.5 mA with DAD6001-BC XLR Adapter
Connector: MicroDot
Microphone length: 10.4 cm (4 in)
Temperature range: -40°C to 45°C (-40°F to 113°F)
Relative humidity (RH): Up to 90%
Color: Black
Weight: 10 g (.35 oz)
1x Microphones 4097 CORE Micro Shotgun Microphone
1x Foam Windscreen
