ATEM215S - SEETEC

Name: ATEM215S - SEETEC
Brand: Seetec
SKU: ATEM215S - SEETEC
Price: 1991974 NGN
Availability: InStock

Seetec

EAN: 6971863813943

Monitor 21,5" IPS, 1920x1080, 4K HDMI 4x 3G SDI in and output

go to the technical sheet

₦ 1,991,974.00

₦ 1,852,999.00 VAT excl.

Available 2 unit in 4 Days

Manufacturer: go to website

Not sure if this is the right product for you? Talk to a consultant

Product description
Specifications

Multiple display mode(1P, PIP, 4P)
1920x1080 full HD IPS screen
Support 3D LUT Log to REC.709 and user 3D LUT upload (up to 36)
Support HDR monitoring
With Waveform, Vectorscope, RGB Histogram, Focus Assist, Monochrome etc. functions, can help you accurately exposure and focus every shot.* Support OSD TALLY and LED TALLY
Stereo Earphone output, bulit-in speaker
In quad split display mode, SDI audio can show 4 channels and 4 time codes
In single display mode, SDI audio can show 16 channels
Supports GPI control
In PIP/quad display mode can be switching signal freely
User custom menu saving function

Standard Accessory
2A DC Power Adapter
V-Mount Battery Plate
U-shaped Bracket
1.5M Mini HDMI Cable
1.5M BNC Cable
Sunshade
Operation Manual

Description: 17.3" 3D LUT Director Monitor
Model: ATEM173S
Screen size: 17.3" IPS
Resolution: 1920×1080 pixels
Display Colors: 16.7M colors 8bits (6-bit + FRC)
Gamut: 72% NTSC
Pixel pitch: 0.1989 (W) x 0.1989 (H) mm
Aspect Ratio: 16:9
Brightness: 300 cd/m²
Contrast: 700:1
Backlight: LED
Response Time: Tr + Tf=25ms
Viewing Angle: 89°/89°(L/R) 89°/89°(U/D)
Inputs: HDMI*1, SDI*4, RS458*1, DPI*1, USB*1
Outputs: SDI*4, RS458*1
Audio: 3.5mm Stereo Headphone, Speaker

SDI Support Format:
720p (60/59.94/50/30/29/25/24/23.98)
1080i (60/59.94/50)
1080p (60/59.94/50/30/29.97/25/24/24sF/23.98/23.98sF)
2048x1080i (60/59.94/50)
2048x1080p (60/59.94/50/30/29.97/25/24/23.98)

HDMI Support Format:
480i/576i/480p/576p
720p (60/59.94/50/30/29.97/25/24/23.98)
1080i (60/59.94/50)
1080p (60/59.94/50/30/29.97/25/24/23.98)

Power Consumption: =22W
Input Voltage: DC 12V
Operating Temperature: 0°C - 50°C
Storage Temperature: -20°C - 60°C
Unit Size: 425L×296H×23D (mm) (without bracket)
Unit Weight: 2.84kg (without bracket)
