SL MCR 4 DW-3

Multi-Channel Receiver

For SpeechLine Digital Wireless with 4 SL DW RF connections
Frequency range: 1880 - 1930 MHz
2 Dante interfaces and PoE power supply
Automatic frequency and interference management
Automatic audio level adjustment
AES 256 encryption
Analogue mix output and integrated auto mixer
Wall, ceiling or microphone stand mounting
Dimensions: 180 x 180 x 45 mm (incl. wall mount)
Weight: 650 g (incl. wall bracket)
Colour: White (RAL 9016)
Incl. wall bracket and drilling template


SL MCR 2 DW-5
Overview

Two or four channel receiver for SpeechLine Digital Wireless
The SpeechLine Multi-Channel Receiver with its 2 or 4 channels is the perfect addition to the SpeechLine series. Thanks to its unobtrusive design, the Multi-Channel Receiver can be installed quickly and easily in any room, whether on the wall or ceiling. The device can be operated with a single network cable, thanks to PoE and Dante. Complex analog audio cabling is a thing of the past. The Multi-Channel Receiver also offers a convenient solution for existing installations. Thanks to an integrated auto mixer and the analog mix output, all audio channels can be used simply as a sum signal. The audio mix is also available digitally via Dante, which allows an extension of the existing setup without exchanging the DSP. Due to the bidirectional communication between receiver and transmitter, all settings of the mobile transmitters can easily be made in the Sennheiser Control Cockpit. The receiver's automatic frequency management eliminates the need for manual frequency settings and the automatic interference management guarantees maximum transmission reliability. The user-friendly pairing function ensures a reliable connection between transmitter and receiver. Network integration also makes it possible to remotely control and monitor the receiver via a media control system (e.g. AMX, Crestron, Q-SYS Control). Due to the integrated antennas, a complex antenna installation is no longer necessary.
Features

Automatic Gain Control
Automatic Frequency management
AES 256 encryption
2-port Dante
PoE
Analog Mix Output
One status LED per Link
Remote control via Control Cockpit or media control
Wall, ceiling or mic stand mounting
Integrated Automixer
DDM Ready
