POV-3G 385

Name: POV-3G 385
Brand: ON-AIR
SKU: POV-3G 385
Price: 500.66 EUR
Availability: OutOfStock

ON-AIR

OSYBZ CCTV Industrial 3G SDI Camera Using 1/2" Sony IMX385 CMOS Sensor

go to the technical sheet

€ 500,66

€ 465,73 VAT excl.

Available in 34 days

Manufacturer: go to website

Not sure if this is the right product for you? Talk to a consultant

Product description
Specifications

ON-AIR HD-SDI camera 2.0MP 1080P 1080i 60fps/50fps 3G SDI HDMI dual output Lens 2.8-12mm Security Box SDI Camera.
1080P high definition image quality, effective resolution reaches 1920x1080, no delay, no compression, low loss and real-time transmission.

Features:

- 1/2" 2.1 Mega Pixel Panasonic CMOS Sensor
- 1920x1080P Full HD Resolution
- HD/EX-SDI video signal output
- WDR, 3DNR, BLC functions
- Support Privacy Zone
- Motion Detection
- OSD Menu(Support English, Italian, Dutch, French, Spanish,German or Russian)
- This module can work at -40° Celsius.

Image Sensor Color: 1/2" Sony IMX385 CMOS Sensor
Total Pixels: 1952 (H) x 1241 (V) Approx. 2.42 Mega Pixel
Effective Pixels: 1945 (H) x 1225 (V) Approx. 2.38 Mega Pixel
Scanning System: Progressive
Resolution Digital: 1080P (60fps/30fps)
Min-Illumination Color: 0.00001Lux, Color: DSS: 0.000001Lux.
Video Digital Output: EX-SDI (1080p); Analog Output: HD-ADH (1080P), CVBS (960H)
S/N Ratio: More than 42dB (AGC off)
ACE & WDR: Off/Low/Middle/High; WDR SNR: 120dB
Lens: 2.8-12mm
Brightness: 0-20
AGC: 0-10 steps
Sens-up: Off/X2/X4/X8/X16/X32
Shutter Speed: AUTO/MANUAL (1/5060-1/60,000 sec)
Defog: Off/On, Low/Middle/High
Shading: Off/On
BLC: Off/BLC
Day & Night: Off/HLC
Color (AWB) Auto/Color/B&W/EXTERN
DNR: Auto/Auto Ext/Preset/manual
Mirror: Off/On
H-V-REV: Off/On
Sharpness: 0-10 Steps
Digital Zoom: 1.0X-16.0X
Motion: Off/on, Alarm Output
Privacy Mask: 24 Masks
Language: English/Chinese
Power (Max.): Supply DC12V+-10% less 1.8W
Video Output: EX-SDI & HDMI
EX-SDI Distance: BNC Cable 75-3 can transmit 500 meters or above.
