TriCaster Mini X

Network Video Input 8 IP video inputs via NDI®, resolution independent

Digital video input

4 HDMI video connections supporting video input in any combination of standards
formats, resolutions and frame rates 1
- 2160p: 29.97, 25
- 1080p: 59.94, 50, 29.97, 25
- 1080i: 59.94, 50
- 720p: 59.94, 50, 29.97, 25
- SD: 59.94, 50, 25
1 Available frame rates determined by session video standard (NTSC or PAL)

PTZ

Support for up to 8 simultaneous Pan-Tilt-Zoom (PTZ) robotic cameras via serial
and network protocols, including RS232 *, RS422 * and IP, with built-in controls
and preset system
* Requires USB to Serial Adapter - sold separately
Skype TX Native support for up to 2 simultaneous Skype® video call inputs via Skype TX
software integration, including counting and Talk Back communication

Network video output
IP video output via NDI, optionally configurable for:
- 4 independent video mix outputs
- 1 UHD video mix output
Stream Output 2 independently configurable streaming video outputs with simultaneous streaming
archive
Monitor Outputs 4 mini display ports with output adapters
3 of the outputs support multiviewers using standard display resolutions

Mix / Effect Bus (M / E)
4 M / E buses supporting video indentation
1 x Mix / Effects bus channel with support for up to 2 sources
2 layers KEY per bus
DSK channels 2 x DSK channels
Multimedia 5 x media players (2 x DDR, 2 x GFX, 1 x audio)
15 x Media Buffers (10 x Live Link or Animation Buffer, 5 x Graphic Buffer)
Keys

LiveMatte ™ chroma and luma keying technology integrated on all sources
channels and M / E buses
- 8 input keyers
- 2 keys for media player
- 4 M / E keys
- 15 keyer buffers
Virtual Sets Integrated LiveSet ™ technology with over 30 virtual live sets and box effects included
DataLink

Integrated DataLink ™ technology that enables automated data entry in real time
internal and external sources, including web pages, spreadsheets, scoreboards,
database, RSS feed, control file, XML, CSV, ASCII and more

Macro

Records, archives, modifies and automates user-configured commands and operations
sequences
- Connect to control panel buttons, keyboard shortcuts, hotspots, MIDI and X-keys®
buttons or GPI triggers
- Attach to internal events and status changes, including audio, media playback,
tally and specific switching actions
- Supports web-based interface control
Registration
4 channels of recording from NDI® inputs or Mix outputs
- Record and retain alpha channel data
- 4 QuickTime® archive video recorders (native NDI codec for recording) 2
2 QuickTime Player not required for playback in common NLE applications

Storage capacity varies based on file format, resolution and specifications
Supports recording to external memory via USB 3.0
Grab Grab full resolution and deinterlaced still images from external video sources e
exits
Export Export video and image files to social media, FTP, local or external volumes and
network server, with optional transcoding
Audio Mixing Integrated multi-channel audio mixer with support for stereo and DSP audio

Local audio input
2 built-in digital audio inputs via HDMI conversion
-1 1/4 "(6.35mm) balanced microphone.
- 2 x 1/4 "(6.35mm) balanced wire.

Local audio output
2 integrated digital audio outputs via HDMI conversion
- 2 x 1/4 "(6.35mm) balanced wire.
- 1 1/4 "(6.35mm) stereo headphone jack.
Network audio
Native support for network audio input and output via NDI® Integrated audio
supported for all NDI® input and output video signals · Built-in support3 for
Audinate® 3''s Dante ™ network protocol requires the Dante virtual sound card
Audinate license (sold separately)

Supported media file formats

Import, store and play media files, with optional transcoding, including:
Video: AVI, DV, DVCPro, DVCProHD, FLV, F4V, H.263, H.264, MOV, MKV,
MJPEG, MPEG, MP4, WMV, WebM and more Image: PSD, PNG, TGA, BMP,
JPEG, JPEG-XR, JPEG2000, EXR, RAW, TIF, WebP and moreAudio: AIFF,
MP3, WAV and more
YCbCr + A 4: 4: 4: 4 floating point video processing Audio: floating point, 96 kHz
Processing Latency: ~ 1.0-1.5 frames
Practical throughput latency: 4 frames
Tally Support for network counting via NDI®
MIDI Support for the standard MIDI protocol that allows control of third party devices
NIC 2 x 1 Gigabit NIC

System physicist

NewTek Mini X system chassis, including adjustable handle and cable attachment
brackets
- (10.74 x 23.1 x 20.1)
- - 8.4 lbs (3.8 kg)

NewTek TriCaster Mini X HDMI
Keyboard
Mouse
4 x Mini DisplayPort to HDMI Adapter
Power Cable
Limited 1-Year Warranty
