Zenmuse L2 - Care 2Y

DJI High Precision IMU System, 4/3 CMOS RGB Mapping Camera with 2 Years Care - DJL202

Zenmuse L2 integrates LiDAR frames, an in-house developed high-precision IMU system, and a 4/3 CMOS RGB mapping camera, providing DJI flight platforms with more precise, efficient, and reliable geospatial data acquisition.
When used with DJI Terra, it offers a turnkey solution for 3D data collection and high-precision post-processing.

Supported by its powerful hardware, L2 can enable precise scanning of complex subjects within an extended range and faster point cloud acquisition. During operations, users can preview, playback and process point cloud models on site, with activity quality reports generated by DJI Terra, offering a simple and comprehensive solution to improve overall efficiency.
This allows users to achieve high-precision point cloud results with unique post-processing.

° High level precision
Combining GNSS and an in-house developed high-precision IMU, this solution achieves a vertical accuracy of 4cm and a horizontal accuracy of 5cm. 1

° Intuitive operation
In combination with Matrice 350 RTK and DJI Terra, L2 offers a simple to use turnkey solution, lowering the operational threshold.

° Increase in detection range by 30% 5
L2 can detect from 250 meters with 10% reflectivity and 100 klx, 3 and up to 450 meters with 50% reflectivity and 0 klx. 3 Typical operating altitude now extends up to 120 meters, significantly improving operational safety and efficiency.

° Point cloud effective speed: 240,000 points/s
In both single and multiple return modes, the L2 can achieve a maximum point cloud output rate of 240,000 points per second, enabling the acquisition of more point cloud data in a given time interval.

° 4/3 CMOS, mechanical shutter
The pixel size has been expanded to 3.3 µm and the effective pixels now reach 20 MP, resulting in a significant improvement in the overall image and more enriched true-color point cloud details.
The minimum interval between photos has been reduced to 0.7 seconds.
The mapping camera can count up to 200,000 shutters, further reducing operating costs.
When point cloud collection is not necessary, the RGB camera can still take photos and record videos or collect images for visible light mapping.
