Layer 3

The stackable PoE Layer 3 Gigabit Managed Switch offers high-density performance, Layer 3 static routing, Routing Information Protocol (RIP), and Open Shortest Path First (OSPF). With a 128 Gbps switching structure, the SGS-6341-24P4X is capable of handling extremely large amounts of data in a secure topology by connecting to a corporate backbone or high-capacity server. Powerful Weighted Round Robin (WRR) and Network Security features make the SGS-6341-24P4X perform effective data traffic control for ISP and VoIP applications, video streaming and corporate multicast. The SGS-6341-24P4X has 24 IEEE 802.3at PoE + ports and a PoE budget of up to 370 watts to suit medium to large scale VoIP or IP surveillance networks at a competitive cost.

Centralized power management for Gigabit Ethernet PoE networks

To meet the demands of the highest PoE network applications required with Gigabit speed transmission, the SGS-6341-24P4X is equipped with high performance IEEE 802.3af Gigabit PoE (up to 15.4 watts) and IEEE 802.3at PoE + ( up to 30 watts) on all ports. Perfectly meets the power requirements of VoIP PoE phone and all kinds of PoE IP cameras such as IR cameras, PTZ, speed dome or even box type IP cameras with built-in fan and heater.

The PoE capabilities of the SGS-6341-24P4X also help reduce implementation costs for network devices as a result of freeing from restrictions on power outlet locations. Power and data switching is integrated into a single unit, delivered via a single cable and centrally managed. This eliminates the cost of additional AC cabling and reduces installation time.

PoE program for energy saving

Besides being used for IP surveillance, the SGS-6341-24P4X is certainly applicable to build any PoE network, including VoIP and wireless LAN. Under the trend of energy saving around the world and contributing to the protection of the environment on Earth, the SGS-6341-24P4X can effectively control the power supply in addition to its ability to provide high power output. The "PoE Schedule" feature allows you to enable or disable PoE power for each PoE port during specified time intervals and is a powerful feature to help SMEs or businesses save energy and budget.


High performance 10 Gbps Ethernet capability

The four SFP + slots integrated in the SGS-6341-24P4X boast a high-performance switch architecture capable of providing a non-blocking switch structure and wire-speed throughput of up to 128 Gbps, which greatly simplifies the upgrade tasks of the SGS-6341-24P4X. LAN for catering to growing bandwidth demands. Each of the SFP + slots supports Dual-Speed, 10GBASE-SR / LR or 1000BASE-SX / LX, which means that the administrator can now flexibly choose the suitable SFP / SFP + transceiver based on the transmission distance or transmission speed. transmission required to extend the network efficiently.


IP stacking management

The SGS-6341-24P4X supports the IP stacking function which helps network managers to easily configure up to 24 switches of the same series via a single IP address instead of connecting and setting each unit one by one. IP Stacking technology brings together the SGS-6341 PLANET switch series to enable centralized management through a single unit, regardless of physical location or switch type, as long as they are connected to the same local network.
