327RC2

Ball Head with 200PL-14 Quick Release Plate

Ball Head with Control Handle
Load Capacity: 8.8 lb
Integrated Handle Squeeze Trigger
90° Forwards and 90° Backwards Tilt
Up to 90° Portrait Angle Tilt
360° Rotation, Built-In Bubble Level
Ball-and-Socket Tension Control
Durable and Lightweight Construction
RC2 Quick Release Lock/200PL-14 QR Plate
1/4"-20 Mount, Non-Slip Surface


This 324RC2 Ball Head from Manfrotto has a load capacity of 8.8 lb and can be attached to tripods or other support systems that feature a 3/8"-16 mount. It includes an RC2 quick release cam lock and a 200PL-14 Quick Release Plate. RC2 compatible quick release plates such as the 200PL-14 can be removed from the head by pulling the cam lock's spring-loaded lever, which also allows the plate to be instantly reattached. The cam lock also features a safety catch to prevent a quick release plate from accidentally disconnecting.

The 324RC2 features a ball-and-socket joint with an easy-to-grip control handle. By squeezing the control handle's integrated trigger, the ball-and-socket joint can be quickly swiveled, angled, fully tilted, or returned to its upright position. A thumbwheel set within the underside of the control handle can be rotated to apply tension control to the ball-and-socket joint's movements. Once the squeeze trigger is released, any adjustments to the position of the ball-and-socket joint are locked into place.

Cameras or accessories that are compatible with a 1/4"-20 mount can be connected to the 200PL-14 quick release plate, which measures 1.7 x 2.1 x 0.4" and has a rubberized, non-slip surface. The 324RC2 is initially configured for use with the right hand. An included hex key allows the RC2 quick release cam lock to be repositioned along with the control handle, enabling left-handed use.
324RC2 Ball Head

8.8 lb load capacity
Compatible with tripods or support systems that feature a 3/8"-16 mount
Uses ball-and-socket joint with easy-to-grip control handle to help maximize pan-and-tilt flexibility
By squeezing the control handle's integrated trigger, the ball-and-socket joint can be quickly swiveled 360°, fully tilted down to a 90° angle, or returned to its upright position
When the control handle's squeeze trigger is released, any adjustments to the position of the ball-and-socket joint are locked into place
A thumbwheel set within the underside of the control handle can be rotated to apply tension control to the ball-and-socket joint's movements
RC2 quick release cam lock
Built-in bubble level
Can be configured for left-handed use
Durable and lightweight aluminum, polymer, and fiberglass construction
Hex key to adjust position of RC2 quick release cam lock
Hex key to adjust tension on ball-and-socket joint

200PL-14 Quick Release Plate

Compatible with Manfrotto RC2 quick release cam lock
Measures 1.7 x 2.1 x 0.4" and has a rubberized, non-slip surface
1/4"-20 mount
Durable, aluminum-alloy construction

UPC: 719821312529
