Libec

4986397461074
H35 75mm Ball and Flat Base Video Head with Pan Handle (17.6 lb/8 kg Payload)
go to the technical sheet
€ 1.246,29

€ 1.159,34 VAT excl.

Available in 14 days
Not sure if this is the right product for you? Talk to a consultant
Libec H35 75mm Ball and Flat Base Video Head with Pan Handle (17.6 lb/8 kg Payload)

Integrate a fluid head into your tripod configuration with various adjustment features using this H35 75mm Ball and Flat Base Video Head with Pan Handle from Libec.
An included pan handle makes for easy movement up and down or side to side.
Independent pan and tilt adjustments make movements intuitive and smooth.
The H35 head has a load capacity of 17.6 lb and an adjustable counterbalance range of 6.6 to 16.5 lb/3 to 7.50 kg.

Your camera is secured via a 1/4"-20 screw and locating pin, and additional 3/8"-16 and 1/4"-20 screws are included for further attachments.
The head also comes with a long sliding plate with one 3/8"-16 screw and one 1/4"-20 screw.
An illuminated bubble level ensures your configuration is level when mounted onto tripod legs.
The H35 is compatible with Manfrotto or Sachtler heads.

Camera Plate Features: Sliding Balance Plate
Camera Mounting Screw:
1 x 1/4"-20 Male with Locating Pin
1 x 1/4"-20 Male
1 x 3/8"-16 Male
Balance Plate Sliding Range: 1.2" / 30 mm
Base Mount: 75 mm Half Ball
Counter Balance: Continuous / 3 to 7.5 kg
Center of Gravity: 3.9" / 100 mm
Included Pan Handle Length: 10.8" / 275 mm
Bubble Level: 1 x Illuminated
Accessory Mounting:
1/4"-20 Female Thread
3/8"-16 Female Thread
Drag Control
Tilt: Stepped 3-Step
Pan: Stepped 3-Step
Drag Type: Fluid
Vertical Tilt: +90° to -70°
Independent Pan Lock: Yes
Independent Tilt Lock: Yes
Load Capacity: 17.6 lb / 8 kg
Operating Temperature: -8 to 92°F / -40 to 60°C
Weight: 6.2 lb / 2.8 kg

Libec H35 75mm Ball and Flat Base Video Head with Pan Handle (17.6 lb Payload)
Long Sliding Plate
Spare 1/4"-20 and 3/8"-16 Screws
