Arri

Center Mount blue/silver Schuko 2,800-10,000K -
go to the technical sheet
₦ 12,530,683.00

₦ 11,656,449.00 VAT excl.

Available in 7 days
Manufacturer: go to website
Not sure if this is the right product for you? Talk to a consultant
L0.0012948 S120-C Center Mount blue/silver Schuko

The highly acclaimed ARRI SkyPanel series of LED soft lights is growing, with the new SkyPanel S120-C joining the S60 and S30 family of products. The S120 is twice as long as the S60, but weighs nearly the same. Its larger light aperture makes a great soft light even better. Retaining the same features and color tuneability as its smaller counterparts, the S120 consumes less than 400 watts, yet it is slightly brighter than the S60-C and has an outstanding efficacy of 90 lumens per watt.

A large surface area is a crucial feature of a good soft light. With an aperture of 1290 mm x 300 mm (50.8" x 11.8"), the S120 outputs a beautifully soft, even beam of light that has a wide range of uses. The long aspect ratio wraps light around objects and is perfect for vertical lighting of people. In addition the S120 works well as an overhead light for large areas, with the increased dimensions meaning that fewer lights and less cables are required.


Released alongside the S120 are all the accessories needed for sculpting and controlling the light. Among the S120 accessories are honeycombs, eggcrates, barndoors, diffusion panels, the SkyBender and a new fabric barndoor called the FlexDoor. This wide range of accessories makes the S120 more versatile and easier to control.

126BMUAC
Manfrotto

126BMUAC

₦ 622,639.00 VAT included
Available in 14 days
A1035CS
Avenger

A1035CS

₦ 1,087,845.00 VAT included
Available 2 unit in 4 Days
MLLC2201K
Manfrotto

MLLC2201K

₦ 1,511,234.00 VAT included
Available 1 unit in 4 Days
L2.0007494
Arri

L2.0007494

₦ 282,509.00 VAT included
Available in 8 days
MLLC3301K
Manfrotto

MLLC3301K

₦ 1,673,451.00 VAT included
Available in 14 days
MLLC1101K
Manfrotto

MLLC1101K

₦ 862,095.00 VAT included
Available in 14 days
L2.0010382
Arri

L2.0010382

₦ 975,024.00 VAT included
Available in 19 days
MLLC1201K
Manfrotto

MLLC1201K

₦ 1,186,638.00 VAT included
Available in 14 days
AMMFCSP120S
Arri

AMMFCSP120S

₦ 2,478,895.00 VAT included
Available in 14 days

Lamphead S120-C
Optical System Soft Diffusion Panel
Light Aperture 1290 x 300 mm / (50.8 x 11.8 inches)
Beam Angle 110° (Half Peak Angle)
Weight Center Mount: 13.7 kg (30.2 lbs)
Manual Version: 16 kg (35.3 lbs)
Pole Op Version: 19.6 kg (43.2 lbs)
Handling Aluminum Yoke, High Strength Tilt Lock
Pole Operation Option (Pan & Tilt)
Mounting 28 mm Spigot (Junior Pin)
Tilt Angle +/- 90º
Lamphead Voltage Input 48 V =
Power Consumption 400 W Nominal, 430 W Maximum
Lamphead Power Connection Male 3-Pin XLR to 15 Amp (Pin 1: Negative / Pin 2: Positive)
Battery Connector Male 4-Pin XLR to 10 Amp (Pin 1: Negative / Pin 4: Positive)
Battery DC Voltage Range 23 - 36 V =
Battery Mode Light Output 50 % of total output
White Light 2,800 K to 10,000 K continuously variable correlated color temperature
Colored Light Full RBG+W color gamut with Hue and Saturation control
Color Temperature Tolerance +/- 100 K (nominal), +/- 1/8 Green-Magenta (nominal)
Color Rendition CRI Average > 95
TLCI Average > 90
Green-Magenta Adjustment Continuously adjustable (Full Minusgreen to Full Plusgreen)
Dimming 0 - 100% continuous
Control On-Board Controller, 5-Pin DMX In and Through, EtherCon LAN network connectivity, USB-A, Art-Net
Remote Device Management (RDM*):
*RDM Available in Future Firmware DMX Setup, Hour Counter and Standard RDM commands
Software Interface Ethernet: DMX Setup, Fixture Status and Firmware Upgrade through PC, Mac
USB-A: Software Upgrade via flash drive
Housing Color Blue/Silver, Black
Ambient Temperature Operation -20 to +45º C (-4 to +113º F)
IP Rating IP20
Estimated LED Lifetime (L70) 50,000 hours
Estimated Color Shift Over Liftetime +/- 5 %
Certifications CE, CB, ENEC, cNRTLus, FCC, PSE

Power Supply Unit S60/S120 PSU
Power Supply Input Range 110 to 240 V ~, 50/60 Hz
Power Supply Output Rnage 48 V =
Power Input Connection powerCON TRUE1 (Bare Ends / Schuko / Edison cables available)
Power Output Connection Female 3-Pin XLR to 10 Amp (Pin 1: Negative / Pin 2: Positive) powerCON TRUE1 (mains power through)
Weight 3.5 kg (7.7 lbs.)
Dimension 383 x 191 x 91 mm (15 x 7.5 x 3.6 inch)
Control On-Board On/Off Switch
Mounting SkyPanel PSU Super Clamp Adapter / Rail Mount Adapter
Certifications CE, CB, ENEC, cNRTLus, PSE
