Control HST-WH

Name: Control HST-WH
Brand: JBL
SKU: Control HST-WH
Price: 534.55 EUR
Availability: OutOfStock

JBL

100W 2-Way 5.25" Passive Wide-Coverage Speaker (Single, White)

go to the technical sheet

-2.5%

Save 2.5%

€ 534,55

€ 497,26 VAT excl.

€ 548,26

Available in 19 days

Manufacturer: go to website

Not sure if this is the right product for you? Talk to a consultant

Product description
Specifications

The black JBL Control HST is a single two-way 100W passive wallmount speaker offering extremely wide coverage and a broad frequency response for music reproduction and paging applications in a variety of indoor and outdoor environments such as stores, restaurants, educational facilities, hotels, and lobbies.

The ABS enclosure features a wall-facing 5.25" woofer and dual horizontally splayed 0.75" fluid-cooled tweeters, enabling the Control HST to deliver a 180 x 160° pattern control while producing a 50 Hz to 20 kHz frequency range (-10 dB) devoid of the primary reflection that normally plagues wall-mounted speakers, making it ideal for reducing the number of speakers in a setup without sacrificing coverage area or fidelity.

An integrated 60W multi-tap transformer allows the Control HST to be used in 70/100V, or 8-ohm system configurations at selectable wattage settings. Boasting IP54 and Mil-Std-810 ratings for resistance to water, humidity, and more, the Control HST is a capable speaker for a range of locations. It includes a color-matched U-bracket for simplified wallmount installation.

Components Four 130 mm (5 in) LF drivers
Sixteen 25 mm (1 in) HF drivers
Frequency Range (-10 dB) 60 Hz - 20 kHz
Coverage Vertical (selectable via switch)
Narrow Mode: 25° (2 kHz - 16 kHz) (±10°)
Broad Mode: 45° (750 Hz - 16 kHz) (±10°)
Horizontal 150° (500 Hz - 8 kHz, ±20°)
Sensitivity (2.83V@ 1m) Narrow: (speech mode) 98 dB (1 kHz - 8 kHz)
(music mode) 93 dB (300 Hz - 18 kHz)
Broad: (speech mode) 96 dB (1 kHz - 8 kHz)
(music mode) 92 dB (300 Hz - 18 kHz)
Nominal Impedance 8 ohms
Power Capacity 500 W (2000 W peak), 2 hrs
350 W (1400 W peak), 100 hrs
Max SPL Narrow: (speech mode) 125 dB cont ave (131 peak)
(music mode) 120 dB cont ave (126 peak)
Broad: (speech mode) 123 dB cont ave (129 peak)
(music mode) 119 dB cont ave (125 peak)
Transducers
Low Frequency Drivers 4 pcs, 130 mm (5 in) drivers, dual magnet neodymium, 38 mm (1.5 in) voice coil, damped blended textile surround, coated diaphragm for moisture, UV, and salt resistance, shielded.
High Frequency Drivers 16 pcs, 25 mm (1 in) drivers, dual magnet neodymium, encased magnet and coated diaphragm for moisture, UV and salt resistance, shielded.
Enclosure Fiberglass reinforced ABS cabinet, painted aluminum grille
Outdoor Capability IP-55 rated, per IEC529, when installed with optional MTC-PC2 panel cover. UV, moisture and 200-hr ASTM G85 acid-air/salt-spray resistant.
Colors Black or white (-WH)
Insert Points 10 M6 swivel (pan)/tilt (16 mm deep) insert points on back panel.
Mounting Included swivel (pan)/tilt wall bracket provides continuously variable +/-80 degree left-right swivel aiming (at no up/down tilt -- see Bracket Guide for maximum swivel range at various up/down tilt angles), continuously variable +/-15 degree tilt, as well as 5 degree fixed increment points. Ten threaded mounting points located on back panel of cabinet conform to industry standard rectangular 127 x 70 mm (5.0 x 2.75 in) pattern for OmniMount® 60.0 and other compatible third-party brackets. Threaded mounting points can be utilized
for suspension.
Dimensions (H x W x D) 694 x 170 x 237 mm
(27.4 x 6.7 x 9.3 in)
Net Weight 9.5 kg (21 lb)
Included Accessories Swivel (pan) / tilt wall bracket
Optional Accessories MTC-PC2 terminal panel cover
MTC-CBT-SMB1 Stand-Mount Bracket for use with 35 mm heavy duty
speaker stand
MTC-CBT-FM2 flush-mount low-profile wall-mount bracket
