KS112

High Output in an ultra-compact form factor

2000 Watt Class D amplifier module

12-inch, long-excursion driver; 6th order bandpass design

Intrinsic Correction™ tuning and loudspeaker management

Refined, professional appearance looks great in any application

Rugged painted wood enclosure for long life and lasting durability

Deployment in either vertical or horizontal positions with dual M20 speaker pole fittings

Optional KS-LOC security cover prevents unauthorized tampering of controls

Complete EASE & CAD information available online

6-Year Warranty*

SPECIFICATIONS KS112
Configuration 6th-Order Bandpass Subwoofer
LF Transducer 12-inch (305 mm), Cone
Frequency Response (-6 dB) 41 Hz - 108 Hz
Frequency Range (-10 dB) 38 Hz - 121 Hz
Maximum Rated SPL1 128 dB @ 1 m (peak)
Amplifier Class D
2000W (peak)
Cooling Low-noise, variable speed fan
Controls Power On/Off
Gain Control
Rotary encoder
2 x selection buttons
Indicators 2 x Power LED (front and rear)
Input Signal LED
Limiter Active LED
Connectors 2 x locking XLR/F 1/4-inch combo
2 x XLR/M (Loop-thru Output)
1 x locking IEC power connector
AC Power Input Universal power supply 100 - 240 VAC, 50 - 60 Hz
AC Power Consumption 100 VAC, 2.4 A / 120 VAC, 2.0 A / 240 VAC, 1.3 A
Enclosure Details
Enclosure 15 mm Birch Plywood
Color Black (RAL 9011)
Grille Internal woofer cover
Dimensions (HWD) inches 24.5 x 15.5 x 24.25
Dimensions (HWD) mm 622 x 394 x 616
Net Weight 28.4 kg (62.6 lbs)
Shipping Weight 34.5 kg (76 lbs)
Regulatory CE, WEEE, UL, China RoHS, RoHS II, FCC Class B
Included Accessories 4 x Low-Noise, Heavy Duty Casters
Optional Accessories KS112 CVR Transport Cover, KS-LOC Lock-Out Cover
SP-16X Extension Pole, SP-36 Extension Pole
