FF3514N86

Name: FF3514N86
Brand: Manfrotto
SKU: FF3514N86
Price: 1730588 NGN
Availability: OutOfStock

Manfrotto

EAN: 8024221371451

Pantograph Top 4C

go to the technical sheet

₦ 1,730,588.00

₦ 1,609,849.00 VAT excl.

Available in 14 days

Datasheet: Download

Manufacturer: go to website

Not sure if this is the right product for you? Talk to a consultant

Product description
Specifications

Pantograph Top 4C
The pantograph is made of aluminium (P-Al MgSi UNI 3569) and manufactured according to DIN 15560-46.
The attachments at both ends of the pantograph are 16mm, male on the bottom and female on the top.
The load is supported by a steel cable of 2mm. diameter (safety factor 12). Loads up to 12Kg can be suspended using only the patented friction device, while loads up to a maximum of 18kg require the use of the optional springs.
The pantograph can be regulated to keep suspended loads from 1 to 18kg perfectly balanced. By turning the coulored notched ring you can adjust the pantograph's friction, this will ensure that the load remains stable when set in position, but that it will move smoothly up and down when necessary

Download

Datasheet

Download (172.69KB)

Pantograph Top 4C
SPECIFICATIONS
attachment 1/4'''' and retractable 3/8'''' screw attachment type
attachment number 16mm socket attachment type
closed length 38 cm
material aluminum
maximum extension 380
Product - Width 150 mm
safety payload 18 kg
Weight 8.500 kg
