98UH5

Panel Technology IPS
Aspect Ratio 16 : 9
Native Resolution 3,840 x 2,160 (UHD)
Brightness 500 cd/m^2
Dynamic CR 500,000:1
Viewing Angle (H x V) 178 x 178
Surface Treatment Anti-reflection Treatment of the Front Polarizer (Reflectance < 2%)
Orientation Portrait & Landscape
Panel Size 98" class (97.52" measured diagonal)
Pixels (H x V x 3) 24,883,200
Response Time 8ms (G to G) typ
Contrast Ratio (Typ.) 1,200:1
Color Depth 1.06B
External Control RS232C(1), RJ45(1), IR / Light sensor(1)
Digital HDMI(2), DP(1), DVI-D(1)
Audio DVI-D, Component
USB Yes(3) USB 3.0 : 1EA USB 2.0 : 2EA
HDTV Formats HDMI, Display Port : 720p, 1,080i, 1,080p, 2,160p (HDMI_1 : Up to 60Hz, Other : Up to 30Hz), DVI : 720p, 1,080i, 1,080p
CONNECTIVITY (OUTPUT) External Control RS232C(1)
Digital DP(1)
Audio SPDIF(1)
CABINET DIMENSIONS Monitor Dimension (WxHxD) 86.3" x 49.1" x 2.7"
Color Black
Bezel Width Even bezel: 14.9mm
Weight(Head) 194.0 Ibs
Packed Weight 271.2 Ibs
VESA™ Mount 800mm x 400 mm
Carton Dimensions (W x H x D) 92.2" x 54.6" x 15.8"
SPECIAL FEATURES Temperature Sensor Yes
Auto Brightness Sensor Yes
Source Selection DVI-D, HDMI, Display Port, USB
Brightness / Contrast / Backlight Yes
Position / Size Yes
Auto Config / Phase Yes
Advanced Dynamic Contrast, Dynamic Color, Clear White, Skin Color, Noise Reduction, Digital Noise Reduction, Gamma, Black Level
Time Clock, On/Off Time, Sleep Timer, Power on Delay, Auto Off, Automatic Standby
Information Model / Type, Software Version, Serial Number, IP Address, Temperature, Power On/Off History, Homepage
Input Label Yes (PC / DTV)
Auto Power / Source Memory Yes
File Play with USB Yes
Internal Memory 8GB (System 4GB + Available 4GB)
Wi-Fi Dongle Ready
4K Up Scaling Yes
Key Lock Yes
DPM Select Yes
ENVIRONMENT CONDITIONS Operation Temperature 0 °C to 40 °C
Operation Humidity 10 % to 80 %
POWER Power Supply 100-240V~, 50/60Hz
Power Type Built-In Power
Power Consumption-Typ 400W
Power Consumption-DPM Off 2W(RGB)/4W(HDMI/DVI)
Power Consumption-Switch Off 2W (DVI-D, HDMI, DP)
AUDIO Balance Yes
Audio Power 20W (10W x 2) for External Speaker
Sound Mode Standard, News, Music, Cinema, Sport, Game
Clear Voice II Yes
