TriCaster Vizion 1RU 8 SDI IO

TriCaster Vizion 1RU 8 SDI IO

TriCaster Vizion 1RU with 44 inputs and 8 SDI I/O
go to the technical sheet
₦ 75,293,838.00

₦ 70,040,779.60 VAT excl.

Available in 19 days
Not sure if this is the right product for you? Talk to a consultant
VIZRT TriCaster Vizion 1RU with 44 inputs and 8 SDI I/O - This includes 1 year of Standard Support and Viz Flowics Basic for 36 months

TriCaster® Vizion is the latest evolution of this renowned video mixing tool that has been used and trusted by broadcasters, sports networks and live event producers for decades. Offering the latest in IP connectivity, configurable SDI I/O, powerful switching, audio mixing and state of the art graphics, TriCaster Vizion is built for the future.
Now with exciting new AI features and industry leading graphics capabilities with TriCaster Graphics powered by Viz Flowics.

The future proofing isn't limited to features, TriCaster Vizion is the first software and hardware TriCaster that is available to purchase with a perpetual or subscription license with a choice of two different hardware platforms offering the ultimate in production and budget flexibility - equipping your network, team or enterprise for whatever the future may hold.

Vizionary
Using all-important user feedback from the last few years, TriCaster Vizion has been refreshed from the ground up, offering significant updates and groundbreaking features - without losing the TriCaster experience operators know and love.
In addition to the below, Vizion customers can expect to receive exciting new updates to their software as part of any active subscription or support contract:
- 44 External Live Inputs
- 12G connectivity
- HDR Sessions with LUT conversion
- AI Keyer
- UI Refresh
- Programmable outputs
- Macro Aliases
- Roadmap of exciting new features
- Up to 16 configurable SDI I/O
- 10-bit SDR Workflow
- AI Gaze correction
- TriCaster graphics powered by Viz Flowics
- Central I/O configuration panel
- Central record configuration
- Copy/Paste Keyer settings

Centralized I/O configuration
Adding all these new, exciting features to Vizion doesn't mean that your productions are any more complex, quite the opposite.
A highly requested feature and one we are excited to bring to life is the all-new set-up tab which allows for centralized location for input, output, SDI, programmable outputs and HDR color settings configuration.
We've created this central area to ensure the user doesn't have to spend valuable time moving between menus and screens.
TriCaster Vizion puts all this integral information in one easy location enabling more efficient productions and workflows.

10-bit SDR/HDR Workflows
TriCaster Vizion will offer native 10-bit support to truly bring stories to life in vibrant life-like color.
In addition, Vizion will be able to send/receive content with HDR sessions in PQ and HLG profiles through NDI High Bandwidth and NDI HX with HEVC codec.
All-new look-up tables (LUTs) allow for color conformance inside your session.
These enhancements offer unparalleled contrast, unlimited color combinations and impressive compatibility across HDR devices.

Live Link for TriCaster
Live Link allows users to render web pages directly into the TriCaster and pull any web page elements into a production without the need for a 3rd party application.
From graphics or images on a web page to videos from your organization's internal training platforms - Live Link offers the ultimate in production agility and freedom.
Available now on all current TriCasters - ensure you have the very latest update to take advantage of this exciting feature.

Video Input: 44 x simultaneous external video inputs, supporting any combination of compatible sources in resolutions up to UHD at frame rates up to 60fps (2160p 59.94)
Network Video Input: 44 x IP inputs via NDI®, resolution-independent, with support for key and fill
SDI Video Input: 12G/3G/HD SDI connections supporting video input in any combination of standard formats, resolutions, and frame rates
- 2160p 59.94, 50, 29.97, 25 | 1080i: 59.94, 50 | 1080p: 59.94, 50, 29.97, 25 | 720p: 59.94, 29.97, 25
Up to 16 configurable ports depending on hardware version. These ports can be configured for input or output. Up to 8 ports support 12G signals.
Available frame rates determined by session video standard (NTSC or PAL)
Video connections are HD-BNC connectors. HD-BNC to BNC pigtails are provided with your system.
Video Output: Configurable for up to 8 independent HD or 2 UHD video mix outputs, with simultaneous delivery via IP and SDI
Network Video Output: 56 x IP outputs via NDI® (HD sessions only) | 8 x video mix outputs in resolutions up to 1080p at frame rates up to 60fps (1080p 59.94) or 2 x UHD video mix outputs at up to 60 frames per second (2160p 59.94)
- Up to 16 x direct IP source outputs via NDI® translation of local SDI inputs
- 4 x direct IP source outputs via NDI® translation of media players, with support for embedded alpha channel
- 15 x direct IP source outputs via NDI® translation of media buffers, with support for embedded alpha channel
- 3x Multiviewer outputs (if 3 monitors are connected). 4K support on 2x Multiviewer outputs while the 3rd outputs in HD
- 1x User Interface with dedicated multiviewer
- 1x teleprompter output (LiveStory™ Creator)
- 8 x selectable IP outputs via internal NDI® matrix router
SDI Video Output:
° 12G/3G/HD SDI connections, optionally configurable for: 8 x independent 12G/3G/HD video mix outputs supporting standard NTSC and PAL formats, resolutions, and frame rates
Audio: 44 channel integrated audio mixer with support for 8-channel audio, DSPs and 4x8x8 audio input routing SSD
Local Audio Input: Up to 16 x SDI embedded
Local Audio Output: Up to 8 x SDI Embedded
Network Audio:
- Native support for network audio input and output via NDI®
- Embedded audio supported for all NDI®input and output video signals
- Integrated support for Dante™ networking protocol from Audinate®
- Support for AES67 protocol via compatible WDM audio drivers
Media:
- 5 x media players: 4 x DDR | 1 x Sound
- 15 x media buffers: 10 x animation buffers with GIF support | 5 x graphic buffers
COMPs: Integrated LiveMatte™ chroma and luma keying technology on all source channels and M/E buses | 16 x configurable COMP presets per bus
Virtual Sets: Integrated LiveSet™ technology with 30+ live virtual sets and box effects included
DataLink: Integrated DataLink™ technology enabling real-time, automated data input from internal and external sources, including webpages, spreadsheets, scoreboards, databases, RSS feeds, watch files, XML, CSV, ASCII and more
Macros: Record, store, edit and automate commands and user-configured operation sequences
- Attach to control panel buttons, keyboard shortcuts, hotspots, MIDI and X-keys® buttons or GPI triggers
- Attach to internal events and state changes, including audio, media playback, tally and specific switcher actions
- Supports control via web-based interface
Recording:
- 8 x configurable M/E channels
- Up to 16 x physical SDI inputs
- 4 x DDR''s
- 3 x streaming encoders
- Support for growing file playback from DDR''s
- Instant Replay capability on each input
- 44 x total configurable inputs
PTZ: Support for up to 44 simultaneous Pan-Tilt-Zoom (PTZ) robotic cameras via serial and network protocols, including RS232, RS422 and IP, with integrated controls and preset system
Conference Calling: Support for multiple simultaneous video call inputs with Microsoft Skype™, Microsoft Teams™, Zoom Meetings™, Slack, Discord™, and Tencent™ software integration using the Live Call Connect feature
Grab: Grab full resolution, deinterlaced still images from external video sources and outputs
Export: Export video and image files to social media, FTP, local or external volumes, and network servers, with optional transcoding
Monitoring: Support for up to 4 multiviewer displays with configurable workspaces and viewports. 4 outputs are via Display port connection
Signal Monitoring: Integrated waveform and vectorscope, full field rate with digital calibration, color preview and support for ITU-R Rec. 709
Processing: Video: YCbCr + Alpha color space, using 4:2:2:4 | Audio: Floating Point, 96 kHz
Latency: Processing Latency: ~1.0-1.5 frames | Practical Throughput Latency: 4 frames
A/V Standards: 12G-SDI video conforms to SMPTE ST 2082 | HD-SDI video conforms to SMPTE 292M | 3G-SDI video conforms to SMPTE 424M (Level A)
Tally: Network tally via NDI®, and Blackmagic Design® SDI tally standard
