CN10x25 IAS SP1
Canon
PL MOUNT
Outstanding optics, versatility and performance, packaged in an amazingly compact and lightweight design.
Capture stunning 4K quality footage thanks to outstanding optical performance, operability and reliability. This versatile and cinematic 25mm-250mm 10x CINE-SERVO lens offers further reach up to 375mm in Full Frame mode (from the standard 250mm), with its 1.5x extender.
Cinematic look with 4K/8K Optical Quality
Designed to produce sharp images from centre to outer edges, even when paired with 8K cameras. The lens also produces the beautiful warm colour tones synonymous with Canon's cinema lens family.
Wide Focal Length Coverage
The 10x zoom lens can handle a wide range of shooting situations, from 25mm wide angle, to 250mm telephoto, in a single lens. This range can be pushed to 375mm with the built-in 1.5x Optical Extender.
Supports Super 35mm and Full Frame cameras
While the lens fully supports Super 35mm, the built-in extender that increases the image size will make the lens becomes compatible with 35mm Full Frame sensor cameras too.
Mount
PL Mount* : CN10x25 IAS S/P1
EF Mount* : CN10x25 IAS S/E1
Zoom ratio
10x
Built-in optical extender
1.5x
Focal length
25-250mm
(with Extender)
37.5-375mm
Maximum diameter ratio (T-number)
T2.95 at 25 - 187 mm / T3.95 at 250 mm
(with Extender)
T4.4 at 37.5 - 281 mm / T5.9 at 375 mm
Number of iris blades
11 Blades
Angle of view
Aspect Ratio 1.78: 1 (Sensor Size 24.6 x 13.8mm)
52.4° x 30.9° at 25 mm
5.6° x 3.2° at 250 mm
(with Extender)
36.3° x 20.9° at 37.5 mm
3.8° x 2.1° at 375 mm
Aspect Ratio 1.9:1 (Sensor Size 26.2 x 13.8mm)
55.3° x 30.9° at 25 mm
6.0° x 3.2° at 250 mm
(with Extender)
38.5° x 20.9° at 37.5 mm
4.0° x 2.1° at 375 mm
Aspect Ratio 1.9:1 (Sensor Size 38.1 x 20.1mm)
Full Frame (with Extender only)
53.9° x 30.0° at 37.5 mm
5.8° x 3.1° at 375 mm
Aspect Ratio 1.5:1 (Sensor Size 36 x 24mm)
Full Frame (with Extender only)
51.3° x 35.5° at 37.5mm
5.5° x 3.7° at 375 mm
Minimum shooting distance
1.2 m / 4.0''
Shooting range at closest approach
Aspect Ratio 1.78: 1 (Sensor Size 24.6 x 13.8mm)
86.5 x 48.5 cm at 25 mm
8.7 x 4.9 cm at 250 mm
(with extender)
57.7 x 32.3 cm at 37.5 mm
5.8 x 3.3 cm at 375 mm
Aspect Ratio 1.9:1 (Sensor Size 26.2 x 13.8mm)
92.1 x 48.5 cm at 25 mm
9.3 x 4.9 cm at 250 mm
(with extender)
61.4 x 32.3 cm at 37.5 mm
6.2 x 3.3 cm at 375 mm
Aspect Ratio 1.9:1 (Sensor Size 38.1 x 20.1mm)
Full Frame (with Extender only)
89.3 x 47.1 cm at 37.5 mm
9.0 x 4.8 cm at 375 mm
Aspect Ratio 1.5:1 (Sensor Size 36 x 24mm)
Full Frame (with Extender only)
84.4 x 56.2 cm at 37.5 mm
8.5 x 5.7 cm at 375 mm
Front diameter 114 mm
